1993 Arctic Cat TIGERSHARK — ELECTRICAL
1993 TIGERSHARK
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3008-120 | REGULATOR/RECTIFIER ASSY | 1 | $587.95 | |
| 2 | 3008-112 | GROMMET, REGULATOR LEAD WIRE | 1 | $9.59 | |
| 3 | 3008-008 | BOLT, 6X25 | 1 | $3.89 | |
| 4 | 3008-178 | CDI UNIT | 1 | $836.29 | |
| 5 | 3008-218 | BOLT,6X20 | 1 | $3.59 | |
| 6 | 3008-122 | CASE, ELECTRIC PARTS | 1 | $690.95 | |
| 7 | 3008-123 | COVER, CASE (GRAY) | 1 | $579.95 | |
| 10 | 3008-007 | BOLT, 6X35 | 1 | $4.29 | |
| 11 | 3008-124 | HOLDER, GROMMET | 1 | $6.59 | |
| 12 | 3008-125 | HOLDER, GROMMET | 1 | $7.79 | |
| 13 | 3008-010 | SCREW, 5X16 (SUS) | 1 | $2.49 | |
| 14 | 3008-169 | BOLT | 1 | $2.29 | |
| 16 | 3008-034 | GROMMET, LEAD WIRE,M10 | 1 | $17.87 | |
| 17 | 3008-362 | GROMMET | 1 | $12.95 | |
| 19 | 3008-180 | CASE ASS'Y, FUSE | 1 | $109.95 | |
| 19 | 0630-024 | FUSE, 15 AMP | 1 | $4.40 | |
| 20 | 3008-658 | SENSOR ASSY,HEAT | 1 | $197.95 | |
| 21 | 3008-113 | GROMMET, BATTERY CABLE | 1 | $19.25 | |
| 22 | 3008-134 | SUPPORTER, ENGINE TEMP SNSR | 1 | $9.59 | |
| 23 | 3003-787 | CABLE TIE | 1 | $4.95 | |
| 24 | 3008-219 | SCREW, 6X10 | 1 | $4.59 | |
| 25 | 3008-040 | CLAMP, HEAT SENSOR,M12 | 1 | $1.92 | |
| 26 | 3008-006 | BOLT, 6X15 | 1 | $3.99 | |
| 27 | 0624-052 | SCREW,CAP-HH-6MM-1.0TX35MM(SS) | 1 | $2.09 | |
| 29 | 0624-082 | WELLNUT 6MM(347-256) | 1 | $3.99 | |
| 30 | 0630-023 | FUSE, 2-1/2 AMP | 1 | $3.19 |
