2018 Arctic Cat ZR 8000 RR ES 137 — DRIVE CLUTCH
2018 ZR 8000 RR ES 137
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0746-888 | CLUTCH,DR.UNCAL-TEAM-HDI33MM (423223) | 1 | $913.95 | |
| 4 | 0646-979 | NUT, JAM 1/4-12 UNF-2B, LENGTH 0.835 | 1 | $33.95 | |
| 5 | 0646-956 | SUBASSEMBLY,SPIDER TP-203-HDI STD RH | 1 | $425.95 | |
| 7 | 0823-396 | SCREW,SHOULDER-HEX SKT .25X2.5 | 1 | $12.35 | |
| 8 | 2623-091 | WASHER, FLAT .500 X .250 X .130 NYLON | 1 | $5.65 | |
| 9 | 0823-399 | NUT,LOCK HEX #10-24 FLEXLOCK | 1 | $9.59 | |
| 10 | 0646-880 | WASHER,FLYWEIGHT THRUST .252X.830X.050 | 1 | $20.63 | |
| 12 | 1623-649 | WASHER,CLUTCH BOLT | 1 | $5.65 | |
| 13 | 1623-792 | BOLT,CLUTCH-M12X1.25X157 | 1 | $26.95 |
