REAR BUMPER, RACK RAIL, SNOWFLAP, AND TAILLIGHT ASSEMBLY
2018 BEARCAT 2000 XT
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 5706-065 | RISER,SEAT-ASSY-PTD BLK | 1 | $174.95 | |
| 2 | 1623-345 | STUD, LATCH- SEAT | 1 | $16.49 | |
| 3 | 1623-083 | NUT,HEX JAM - M10 X 1.25 | 1 | $1.78 | |
| 4 | 8422-002 | NUT,HEX-THK NYL M10X1.25 CL8 Z&Y | 1 | $0.95 | |
| 5 | 0123-802 | WASHER,FLAT .194X.50X.048-Z&Y | 1 | $0.12 | |
| 6 | 8060-706 | RIVET,BLIND-DH SS64 BLK | 1 | $0.40 | |
| 7 | 4606-162 | CABLE, SEAT-22.5" | 1 | $24.77 | |
| 8 | 1623-022 | SCREW,48-2 TXSPNH 1/4-10X.625 Z&Y | 1 | $6.47 | |
| 9 | 8408-616 | SCREW,CAP-HFH M6X1.0X16 CL8.8 Z&Y | 1 | $0.54 | |
| 10 | 1623-984 | CLAMP,WIRE - 76.14MM LG W/6.25 HOLE | 1 | $6.20 | |
| 11 | 4706-072 | KIT,TOOL BAG ASSY (F3 CARB) | 1 | $29.95 | |
| 12 | 0623-579 | HINGE,SEATBASE | 1 | $38.95 | |
| 13 | 5606-802 | SEAL,SEAT BASE (13 1/2")-RISER | 1 | $12.35 | |
| 14 | 5606-803 | SEAL,SEAT BASE (16")-RISER | 1 | $15.11 | |
| 16 | 0441-592 | BUSHING,RACK FRAME | 1 | $4.26 | |
| 17 | 8476-820 | SCREW,MACH-TSTRH M8X1.25X20 Z&Y | 1 | $0.95 | |
| 18 | 4706-258 | MOUNT, RACK-RH-PTD BLACK | 1 | $69.95 | |
| 18 | 4706-259 | MOUNT, RACK-LH-PTD BLACK | 1 | $69.95 | |
| 19 | 8427-802 | NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z&Y | 1 | $0.54 | |
| 20 | 1623-782 | SCREW,MACH-TSTRH M6X1.0X20 RIE BLK | 1 | $1.92 | |
| 21 | 0623-184 | WASHER,FLAT 1/4 X 1.0 Z&Y | 1 | $1.95 | |
| 22 | 3606-740 | SNOWFLAP-BCWT | 1 | $125.95 | |
| 23 | 8427-602 | NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z&Y | 1 | $0.12 | |
| 24 | 8476-835 | SCREW,MACH-TSTRH M8X1.25X35 Z&Y | 1 | $3.59 | |
| 25 | 4706-065 | BUMPER, REAR-PTD BLK | 1 | $362.95 | |
| 26 | 5611-853 | DECAL,WARNING-TOWING/TRACK-ENGLISH | 1 | $2.47 | |
| 27 | 5611-852 | DECAL,WARNING-TOWING/TRACK-FRENCH | 1 | $2.47 | |
| 28 | 4606-156 | HITCH, PINTLE | 1 | $84.95 | |
| 29 | 8050-242 | WASHER,FLAT- 5/16 X .625 X .063 Z&Y | 1 | $2.06 | |
| 30 | 8408-832 | SCREW,CAP-HFH M8X1.25X30 CL8.8 W/204(RED | 1 | $12.35 | |
| 31 | 0609-887 | TAILLIGHT,LED-1.5" X 9.5" (55" LEAD)RED | 1 | $112.95 | |
| 32 | 1623-786 | CLAMP,WIRE-HALF-3/8"-VINYL COATED | 1 | $16.49 | |
| 33 | 0623-301 | SCREW,SELF TAP-HWH 10X1/2 AB Z&Y | 1 | $0.12 |
