2017 Arctic Cat BEARCAT 7000 XT — HOOD ASSEMBLY
2017 BEARCAT 7000 XT
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 3 | 2621-854 | DECAL,CAUTION-SHIFT-ENG/FR | 1 | $20.63 | |
| 4 | 2621-323 | DECAL,WARNING-ENGLISH | 1 | $19.25 | |
| 5 | 2621-322 | DECAL,WARNING-FRENCH | 1 | $19.25 | |
| 8 | 0617-710 | FOAM,OUTER HOOD-MID-RH | 1 | $8.21 | |
| 8 | 0617-711 | FOAM,OUTER HOOD-MID-LH | 1 | $8.21 | |
| 11 | 2621-667 | DECAL,HOOD-ARCTIC CAT-BLUE | 1 | $4.82 | |
| 14 | 6606-860 | LID,STORAGE BOX-MOLD BLK | 1 | $27.95 | |
| 15 | 6606-915 | COMPARTMENT,STORAGE-HOOD-MOLD BLK | 1 | $17.87 | |
| 16 | 2623-042 | SCREW,SHOULDER-TSBH-M6-1.0 X 18 | 1 | $1.78 | |
| 17 | 2623-058 | SCREW,SHOULDER-TSPNH-M6X1.0X42-RIE BLK | 1 | $20.63 | |
| 18 | 1623-939 | NUT,SPEED-#10 B "U" TYPE | 1 | $1.23 | |
| 19 | 4718-591 | HOOD,CENTER-BLK W/O DECALS | 1 | $209.95 | |
| 20 | 0617-712 | FOAM,CENTER HOOD-RH | 1 | $16.49 | |
| 20 | 0617-713 | FOAM,CENTER HOOD-LH | 1 | $16.49 | |
| 21 | 4411-479 | EMBLEM,AIRCAT | 1 | $5.95 | |
| 22 | 1623-933 | SCREW,PLASTITE-TXSPNH 10-14X3/4 Z&B | 1 | $0.26 | |
| 23 | 6606-611 | CABLE,HOOD-27.5IN | 1 | $32.95 | |
| 24 | 0623-797 | SCREW,SELF TAP-TSTH 10-12X1/2 WO/GP | 1 | $0.45 | |
| 25 | 0623-784 | R/B 2623-163 | 1 | $0.35 | |
| 26 | 5706-800 | BRKT,HOOD HINGE-UPPER-RH-PTD BLK | 1 | $22.01 | |
| 26 | 5706-801 | BRKT,HOOD HINGE-UPPER-LH-PTD BLK | 1 | $24.77 | |
| 27 | 1623-030 | NUT,SPEED-#10B U TYPE | 1 | $0.95 | |
| 28 | 5706-802 | BRKT,HOOD HINGE-LOWER-RH-PTD BLK | 1 | $82.95 | |
| 28 | 5706-803 | BRKT,HOOD HINGE-LOWER-LH-PTD BLK | 1 | $24.77 | |
| 29 | 2623-068 | SCREW,SHOULDER-TSPNH-M6X1.0X28-BLK | 1 | $22.01 | |
| 30 | 0423-577 | CLIP,U-NUT M6 | 1 | $0.40 | |
| 31 | 2623-059 | SCREW,MACH-TSPNH M6X1X16 MPT Z&Y-W/2353 | 1 | $1.78 |
