2016 Arctic Cat ZR 6000 R SX — REAR SUSPENSION FRONT ARM ASSEMBLY
2016 ZR 6000 R SX
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 2704-775 | ARM,FRONT-BLK FABR | 1 | $335.95 | |
| 2 | 3604-702 | BUSHING,GARLOCK (16FDU20) | 1 | $19.25 | |
| 3 | 8413-241 | SCREW,CAP-HFH M12X1.25X40 CL10.9W/2353 | 1 | $8.54 | |
| 4 | 0623-119 | WASHER, FLAT- 1.00 X 1.43 X .075 | 1 | $7.03 | |
| 5 | 3604-701 | AXLE,FRONT ARM | 1 | $37.95 | |
| 6 | 8477-625 | SCREW,MACH-TSTRH M6X1.0X25 Z&BLK | 1 | $0.68 | |
| 7 | 0623-875 | WASHER, BACKING-7MM ID X 11/8OD | 1 | $1.78 | |
| 8 | 3604-891 | STRAP,LIMITER-4 HOLE-425mm LG | 1 | $19.25 | |
| 9 | 8427-602 | NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z&Y | 1 | $0.12 | |
| 10 | 8477-635 | SCREW,MACH-TSTRH M6X1.0X35 Z&BLK | 1 | $0.81 | |
| 11 | 3604-711 | AXLE,FRONT ARM-19 OD X 394.2 | 1 | $57.95 | |
| 12 | 3604-791 | BUSHING,FRONT SLIDER | 1 | $29.95 | |
| 13 | 8408-051 | SCREW,CAP-HFH M10X1.25X50 CL8.8 W/2353 | 1 | $19.25 | |
| 15 | 3604-906 | BEARING,SHOCK FRT ARM-25.45 X 22.4X18.54 | 1 | $5.09 | |
| 16 | 3604-200 | RETAINER,SPRING-POWDER METAL | 1 | $6.06 | |
| 17 | 2704-229 | SPRING,COMP-160/260# X 7.75"-PTD BLK | 1 | $74.95 | |
| 18 | 8408-045 | SCREW,CAP-HFH M10X1.25X45 CL8.8 Z&Y | 1 | $4.68 | |
| 19 | 3604-709 | SPACER,SPHERICAL BEARING | 1 | $4.40 | |
| 20 | 0670-183 | O-RING, 5/8 X 13/16 OD | 1 | $0.26 | |
| 21 | 2623-076 | R/B 2623-202 | 1 | $1.39 |
