2013 Arctic Cat XF 1100 TURBO CROSS-TOUR — INTAKE MANIFOLD/FLANGE ASSEMBLY
2013 XF 1100 TURBO CROSS-TOUR
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3007-785 | PIPE ASSY,INTAKE | 1 | $387.95 | |
| 2 | 3007-786 | GASKET,INTAKE PIPE | 1 | $19.25 | |
| 3 | 3007-446 | BOLT,THERMOSTAT CAP | 1 | $3.44 | |
| 4 | 3007-787 | TANK,SURGE | 1 | $790.95 | |
| 5 | 3007-788 | HOSE,INTAKE PIPE | 1 | $117.95 | |
| 6 | 3007-789 | CLAMP,INTAKE PIPE HOSE | 1 | $32.95 |
