GEARCASE ASSEMBLY
2010 CF8
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 0 | 1702-108 | GEARCASE,FWD-60/60 5P-SPLINED-M ASSY | 1 | $1,357.95 | |
| 0 | 5639-219 | FLUID,GEARCASE-ACT 1-15OZ | 1 | $18.95 | |
| 1 | 0702-998 | GEARCASE,FWD ONLY-ASSY-M | 1 | $302.95 | |
| 2 | 1602-915 | PIN,DOWEL-M5 DIA X 14 | 1 | $2.47 | |
| 3 | 2602-172 | SEAL,OIL-HIGH COMP-50 X 65 X 8MM | 1 | $29.95 | |
| 4 | 2602-151 | SNAP RING (XUMI-151) | 1 | $13.73 | |
| 5 | 1702-012 | GEAR,RING-76T W/BRG | 1 | $275.95 | |
| 6 | 1602-980 | BEARING,50MMX72MMX20MM-PEER | 1 | $46.95 | |
| 7 | 1702-013 | GEAR,PLANETARY-5P-W/ADAPTER ASSY | 1 | $331.95 | |
| 8 | 1602-349 | GEAR,PLANETARY-5 PINION | 1 | $258.95 | |
| 9 | 2602-257 | RING,RETAINING-PLANETARY GEAR(W/O TAB) | 1 | $5.09 | |
| 10 | 0702-691 | SHAFT,INPUT-60T W/BEARING-ASSY | 1 | $174.95 | |
| 11 | 1602-981 | BEARING,25MMX47MMX8MM-PEER | 1 | $17.87 | |
| 12 | 1702-105 | GEAR,TRANSFER-60T/34T-FWD-SPLINED-ASSY | 1 | $267.95 | |
| 13 | 2602-259 | SPACER,BEARING (17MM) | 1 | $2.61 | |
| 14 | 2602-108 | BEARING,TRANSFER GEAR-17mm- PEER | 1 | $8.21 | |
| 15 | 2602-173 | GASKET,GEARCASE (M FWD) | 1 | $24.77 | |
| 16 | 0702-999 | COVER,GEARCASE-FWD ONLY-ASSY-M | 1 | $178.95 | |
| 17 | 2602-160 | SEAL,OIL-PRE LUBE-2.099 X 1.311 X .315 | 1 | $23.39 | |
| 18 | 1602-982 | BEARING,SHAFT-INPUT-30MM-PEER | 1 | $34.95 | |
| 19 | 1602-213 | O-RING,2-013 | 1 | $0.40 | |
| 20 | 2602-099 | PLUG,FILL-12 MM | 1 | $13.73 | |
| 21 | 1623-683 | SCREW,TAPTITE-TSPNH M6 X 1 X 20 Z&B | 1 | $1.23 |
