2008 Arctic Cat BEARCAT WIDE TRACK — HANDLEBAR AND CONTROLS
2008 BEARCAT WIDE TRACK
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0687-188 | CABLE, THROTTLE-SINGLE W/O OIL | 1 | $152.95 | |
| 2 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 | |
| 3 | 2606-084 | GRIP, HANDLEBAR-5.60" | 1 | $16.49 | |
| 4 | 0609-818 | CONTROL, R/H-FRONT-08 4 STROKE | 1 | $79.95 | |
| 5 | 0609-792 | COVER, CONTROL-RH-CONNECTOR RETENTION | 1 | $1.92 | |
| 6 | 0609-793 | SCREW, #4-24 HI-LO X .50" | 1 | $0.26 | |
| 7 | 0609-791 | SCREW,SELF TAP-TXPNH #8-18 X .875 HI-LO | 1 | $0.12 | |
| 8 | 0609-886 | CONTROL,THROTTLE-R/H-REAR (35MM) | 1 | $129.95 | |
| 9 | 0609-859 | KIT, THROTTLE LEVER MOUNTING | 1 | $30.95 | |
| 13 | 0123-766 | NUT,PUSH-.125 STUD | 1 | $1.23 | |
| 14 | 0609-796 | LEVER, THROTTLE-35MM | 1 | $28.95 | |
| 15 | 0617-248 | PAD, INSULATOR-THUMB WARMER | 1 | $1.37 | |
| 16 | 0609-827 | ELEMENT,THUMBWARMER-H/L (15V) | 1 | $74.95 | |
| 17 | 0609-595 | CLIP,RETAINER-TW HARNESS | 1 | $2.47 | |
| 18 | 1705-072 | HANDLEBAR - PTD BLK | 1 | $74.95 | |
| 19 | 1686-454 | HARNESS, HANDLEBAR-08 T660 | 1 | $158.95 | |
| 20 | 0605-845 | PAD, HANDLEBAR-FRONT | 1 | $27.95 | |
| 21 | 0605-846 | PAD, HANDLEBAR-REAR | 1 | $24.95 | |
| 22 | 3706-671 | COVER, HANDLEBAR PAD-07 BCWT | 1 | $77.95 | |
| 23 | 0609-929 | CONTROL,LH-W/O PTT-FRT | 1 | $96.95 | |
| 24 | 0609-883 | CONTROL,L/H-REAR | 1 | $13.73 | |
| 25 | 0609-714 | ELEMENT, HW- H/L-RH | 1 | $86.95 | |
| 25 | 0609-715 | ELEMENT, HW- H/L-LH | 1 | $89.95 |
