2008 Arctic Cat BEARCAT 570 LONG TRACK — HOOD AND WINDSHIELD ASSEMBLY
2008 BEARCAT 570 LONG TRACK
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 2718-088 | HOOD W/DECALS-RED MET-BCLT 570 | 1 | $1,511.95 | |
| 2 | 2718-087 | HOOD W/O DECALS, RED MET-BCLT 570 | 1 | $985.95 | |
| 3 | 0617-478 | FOAM,HOOD-MIDDLE UPR RH | 1 | $19.25 | |
| 3 | 0617-479 | FOAM,HOOD-MIDDLE UPR LH | 1 | $19.25 | |
| 4 | 0617-475 | FOAM,HOOD-MIDDLE | 1 | $15.11 | |
| 5 | 0619-206 | TAPE,ALUM FOIL - 6" X 30 FT | 1 | $7.77 | |
| 6 | 1606-938 | FOIL,HOOD-RH | 1 | $54.95 | |
| 6 | 1606-939 | FOIL, HOOD-LH | 1 | $75.95 | |
| 7 | 0623-797 | SCREW,SELF TAP-TSTH 10-12X1/2 WO/GP | 1 | $0.45 | |
| 8 | 5606-117 | HINGE, HOOD-GUN METAL SILVER | 1 | $52.95 | |
| 9 | 3611-485 | DECAL, WARNING-GENL & BRAKE-ENG & FRNCH | 1 | $35.95 | |
| 10 | 3611-580 | DECAL,REVERSE | 1 | $25.95 | |
| 11 | 3611-970 | DECAL, CAUTION-ENG/BTRY/FUEL-ENG &FRCH | 1 | $41.95 | |
| 12 | 7611-832 | DECAL, HOOD-"AC"-08 BCWT | 1 | $49.95 | |
| 13 | 8611-267 | DECAL,AIRCAT-DYMOFLEX CHROME | 1 | $20.63 | |
| 14 | 7611-837 | DECAL, HOOD, CREST-08 BCLT 570 | 1 | $63.95 | |
| 15 | 7611-840 | DECAL, HOOD-RH-FORWARD-08 BCLT 570 | 1 | $76.95 | |
| 15 | 7611-841 | DECAL, HOOD-LH-FORWARD-08 BCLT 570 | 1 | $76.95 | |
| 16 | 7611-838 | DECAL, HOOD-RH-LOWER-08 BCWT | 1 | $166.95 | |
| 16 | 7611-839 | DECAL, HOOD-LH-LOWER-08 BCWT | 1 | $78.95 | |
| 17 | 1606-067 | STRAP, HOLDDOWN- HOOD | 1 | $12.35 | |
| 19 | 0124-054 | SNAP CAP W/WASHER | 1 | $1.23 | |
| 20 | 0623-902 | SCREW, MACH-PHTRH-10-32X5/8-ZY | 1 | $0.95 | |
| 21 | 0623-845 | NUT, EXP,10-32 | 1 | $2.47 | |
| 22 | 0616-032 | O-RING-WINDSHIELD (1 I.D.) | 1 | $1.78 | |
| 23 | 0123-802 | WASHER,FLAT .194X.50X.048-Z&Y | 1 | $0.12 | |
| 24 | 2606-370 | DUCT, AIR-OUT | 1 | $57.95 | |
| 25 | 8060-508 | RIVET,BLIND-DH SS56 BLK | 1 | $0.26 | |
| 26 | 0617-427 | FOAM, DUCT, AIR-OUT-570-TOP | 1 | $13.73 | |
| 27 | 0617-428 | FOAM, DUCT, AIR-OUT-570-SIDE | 1 | $9.59 | |
| 28 | 0617-425 | FOAM, DUCT, AIR-OUT-570-BOTTOM | 1 | $23.39 | |
| 29 | 2706-407 | SCREEN, VENT-HOOD-CTR-PTD BLK | 1 | $65.95 | |
| 30 | 2706-409 | SCREEN, VENT-HOOD-LH-PTD BLK | 1 | $32.95 | |
| 31 | 2706-408 | SCREEN, VENT-HOOD-RH-PTD BLK | 1 | $63.95 | |
| 32 | 1606-158 | CABLE HOOD 35.0" | 1 | $15.11 | |
| 35 | 1623-016 | SCREW, HEX DOME HEAD -1/4-20 x1.24 Z&Y | 1 | $27.95 | |
| 36 | 0123-394 | CLIP CABLE | 1 | $1.37 |
