2007 Arctic Cat BEARCAT WIDE TRACK TURBO — BATTERY ASSEMBLY
2007 BEARCAT WIDE TRACK TURBO
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0745-230 | BATTERY,E START-TURBO W/FOIL(0645-432) | 1 | $259.95 | |
| 2 | 0645-082 | WRAP,BATTERY HEAT-6 X 11 | 1 | $6.34 | |
| 3 | 0645-412 | CABLE, BATTERY-GROUND-22" | 1 | $26.95 | |
| 4 | 0623-325 | NUT,WING - 1/4-20 NYLON SL | 1 | $2.06 | |
| 5 | 8050-217 | WASHER,FLAT- 1/4 X .625 X .065 Z&Y | 1 | $0.12 | |
| 6 | 0645-243 | STRAP, BATTERY HOLDOWN-TOP | 1 | $16.49 | |
| 7 | 0645-311 | STRAP,BATTERY HOLDOWN-SIDE | 1 | $32.95 | |
| 8 | 8060-484 | RIVET, BLIND-DH SS53 ZINC | 1 | $0.40 | |
| 9 | 0745-273 | TRAY,LGE BATTERY-PTD BLK | 1 | $40.95 |
