2004 Arctic Cat FIRECAT 600 SNO PRO 1 LIMITED EDITION — HOOD AND WINDSHIELD ASSEMBLY
2004 FIRECAT 600 SNO PRO 1 LIMITED EDITION
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3606-019 | WINDSHIELD,RACE-CHROME W/GRAPHIC | 1 | $258.95 | |
| 2 | 1718-497 | COVER, GRN TA HOOD-W/DECALS | 1 | $253.95 | |
| 3 | 5611-654 | DECAL,COVER-UPR RH | 1 | $28.95 | |
| 3 | 5611-655 | DECAL,COVER-UPR LH | 1 | $155.95 | |
| 4 | 5611-188 | DECAL,COVER-RH | 1 | $34.95 | |
| 4 | 5611-189 | DECAL,COVER-LH | 1 | $34.95 | |
| 5 | 1718-483 | HOOD, GRN TA-W/DECALS (F6 CARB) | 1 | $1,487.95 | |
| 6 | 5611-656 | DECAL,HOOD-UPR RH | 1 | $79.95 | |
| 6 | 5611-657 | DECAL,HOOD-UPR LH | 1 | $72.95 | |
| 7 | 5611-200 | DECAL,HOOD-LIGHT RH | 1 | $35.95 | |
| 7 | 5611-201 | DECAL,HOOD-LIGHT LH | 1 | $37.95 | |
| 8 | 5611-646 | DECAL,HOOD-RH "F6" | 1 | $155.95 | |
| 8 | 5611-647 | DECAL,HOOD-LH "F6" | 1 | $141.95 | |
| 9 | 5611-186 | DECAL,HOOD-VENT RR-RH | 1 | $43.95 | |
| 9 | 5611-187 | DECAL,HOOD-VENT RR-LH | 1 | $88.95 | |
| 10 | 5611-184 | DECAL,HOOD-VENT FWD-RH | 1 | $85.95 | |
| 10 | 5611-185 | DECAL,HOOD-VENT FWD-LH | 1 | $85.95 | |
| 11 | 5611-650 | DECAL,HOOD-CONSOLE RH | 1 | $112.95 | |
| 11 | 5611-651 | DECAL,HOOD-CONSOLE LH | 1 | $112.95 |
