2003 Arctic Cat FIRECAT 500 SNO PRO — BELLY PAN AND SEAT ASSEMBLIES
2003 FIRECAT 500 SNO PRO
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 7996-954 | SEAT-MFG ASSY(TA 500/700 GRN) | 1 | $1,070.95 | |
| 1 | 7996-955 | SEAT-MFG ASSY(TA 500/700 BLK) | 1 | $800.95 | |
| 1 | 7996-956 | SEAT-MFG ASSY(TA 500/700 RED) | 1 | $769.95 | |
| 2 | 2706-080 | COVER,SEAT-W/DECALS(TA 500/700 GRN) | 1 | $414.95 | |
| 2 | 2706-081 | R/B 6706-403 | 1 | $510.95 | |
| 2 | 2706-082 | COVER,SEAT-W/DECALS(TA 500/700 RED) | 1 | $594.95 | |
| 3 | 4611-992 | DECAL,BELLY PAN-RH GRN "F5" | 1 | $64.95 | |
| 3 | 4611-993 | DECAL,BELLY PAN-LH GRN "F5" | 1 | $64.95 | |
| 3 | 5611-004 | DECAL,BELLY PAN-RH BLK "F5" | 1 | $64.95 | |
| 3 | 5611-005 | DECAL,BELLY PAN-LH BLK"F5" | 1 | $64.95 | |
| 3 | 5611-012 | DECAL,BELLY PAN-RH RED "F5" | 1 | $64.95 | |
| 3 | 5611-013 | DECAL,BELLY PAN-LH RED "F5" | 1 | $64.95 | |
| 4 | 5611-116 | DECAL,BELLY PAN-LWR GRN RH | 1 | $59.95 | |
| 4 | 5611-117 | DECAL,BELLY PAN-LWR GRN LH | 1 | $72.95 | |
| 4 | 5611-118 | DECAL,BELLY PAN-LWR BLK RH | 1 | $69.95 | |
| 4 | 5611-119 | DECAL,BELLY PAN-LWR BLK LH | 1 | $66.95 | |
| 4 | 5611-120 | DECAL,BELLY PAN-LWR RED RH | 1 | $64.95 | |
| 4 | 5611-121 | DECAL,BELLY PAN-LWR RED LH | 1 | $64.95 |
