2002 Arctic Cat ZR 600 — HOOD AND WINDSHIELD ASSEMBLY
2002 ZR 600
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 1718-028 | HOOD W/DECALS-02 ZR 600 | 1 | $1,185.95 | |
| 2 | 1718-032 | HOOD,W/O DECAL-ZR 500 | 1 | $1,168.95 | |
| 4 | 0617-322 | FOAM,HOOD-UPPER RH | 1 | $42.95 | |
| 4 | 0617-323 | FOAM,HOOD-UPPER LH | 1 | $53.95 | |
| 5 | 0617-326 | FOAM,HOOD-REAR RH | 1 | $17.95 | |
| 5 | 0617-327 | FOAM,HOOD-REAR LH | 1 | $29.95 | |
| 6 | 0617-328 | FOAM,HOOD-MIDDLE | 1 | $26.95 | |
| 7 | 3611-485 | DECAL, WARNING-GENL & BRAKE-ENG & FRNCH | 1 | $35.95 | |
| 8 | 3611-970 | DECAL, CAUTION-ENG/BTRY/FUEL-ENG &FRCH | 1 | $41.95 | |
| 9 | 3611-509 | DECAL, WARNING-SEATING CAPACITY | 1 | $72.95 | |
| 10 | 4611-334 | DECAL,HOOD PAD-ACT-RH BLK | 1 | $8.95 | |
| 10 | 4611-335 | DECAL,HOOD PAD-ACT-LH BLK | 1 | $8.95 | |
| 11 | 1606-938 | FOIL,HOOD-RH | 1 | $54.95 | |
| 11 | 1606-939 | FOIL, HOOD-LH | 1 | $75.95 | |
| 12 | 1606-720 | HINGE, HOOD | 1 | $45.95 | |
| 13 | 0623-797 | SCREW,SELF TAP-TSTH 10-12X1/2 WO/GP | 1 | $0.45 | |
| 14 | 4611-105 | DECAL, HOOD-CTR | 1 | $42.95 | |
| 15 | 4611-367 | DECAL, HOOD-ZR 600 APV TWIN | 1 | $37.95 | |
| 16 | 4611-080 | DECAL,HOOD-LWR-RH | 1 | $136.95 | |
| 16 | 4611-081 | DECAL,HOOD-LWR-LH | 1 | $136.95 | |
| 17 | 4611-082 | DECAL,HOOD-VENT-RR RH | 1 | $19.95 | |
| 17 | 4611-083 | DECAL,HOOD-VENT-RR LH | 1 | $19.95 | |
| 18 | 4611-084 | DECAL,HOOD-VENT-FRT RH | 1 | $20.63 | |
| 18 | 4611-085 | DECAL,HOOD-VENT-FRT LH | 1 | $20.63 | |
| 19 | 3611-187 | DECAL, HOOD-"ARCTIC CAT"-BLK | 1 | $26.95 | |
| 20 | 1606-158 | CABLE HOOD 35.0" | 1 | $15.11 | |
| 22 | 1606-067 | STRAP, HOLDDOWN- HOOD | 1 | $12.35 | |
| 23 | 0623-690 | SCREW,HDHS-1/4-20X1.240 Z&Y | 1 | $24.77 | |
| 25 | 2606-414 | WINDSHIELD-SMOKE-W/O SCREENING | 1 | $203.95 | |
| 26 | 0616-032 | O-RING-WINDSHIELD (1 I.D.) | 1 | $1.78 | |
| 27 | 0124-054 | SNAP CAP W/WASHER | 1 | $1.23 | |
| 28 | 0623-902 | SCREW, MACH-PHTRH-10-32X5/8-ZY | 1 | $0.95 | |
| 29 | 0623-845 | NUT, EXP,10-32 | 1 | $2.47 |
