1993 Arctic Cat EXT 550 — WINDSHIELD, HEADLIGHT, AND HOOD HINGE
1993 EXT 550
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0620-063 | HARNESS,TACH-TEMP&WARMER | 1 | $56.95 | |
| 2 | 0620-064 | HARNESS,SPEEDO-BEAM&OIL | 1 | $58.95 | |
| 3 | 8040-246 | NUT,HEX LOCK-NYL 10-24 Z&Y | 1 | $0.26 | |
| 4 | 0616-160 | POD,HEADLIGHT | 1 | $632.95 | |
| 5 | 1611-539 | DECAL,INSTRUMENT CONSOLE-POD | 1 | $89.95 | |
| 6 | 0706-780 | TRIM,CONSOLE-62 LG. | 1 | $16.95 | |
| 7 | 0620-073 | KNOB,TRIPMETER | 1 | $15.11 | |
| 8 | 0620-066 | SPEEDOMETER W/HI BEAM AND OIL LIGHTS | 1 | $369.95 | |
| 9 | 0620-083 | CUSHION,RUBBER-SPEEDOMETER/TACH | 1 | $13.73 | |
| 10 | 0620-067 | TACHOMETER W/SLR TRIM & TEMP/WARMER LTS | 1 | $311.95 | |
| 11 | 0609-078 | BULB,T 6.5 WEDGE BASE-1 | 1 | $4.95 | |
| 12 | 0230-020 | BULB, T-10 WEDGE BASE-12 V 3.4W | 1 | $3.16 | |
| 13 | 0120-361 | PLATE,RETAINING | 1 | $5.95 | |
| 14 | 0120-457 | BRACKET,SPEEDOMETER-MTG | 1 | $17.87 | |
| 14 | 0120-281 | BRACKET,MTG-TACHOMETER | 1 | $13.73 | |
| 15 | 0623-038 | NUT,HEX M6 Z&Y-SEMS (W/WASHER) | 1 | $0.26 | |
| 16 | 0620-030 | CABLE,SPEEDOMETER | 1 | $60.95 | |
| 17 | 0123-010 | NUT,EXPANSION 10-32 | 1 | $6.75 | |
| 18 | 0123-549 | SCREW,MACH-PHTRH 10-32 X 1.00 Z&Y | 1 | $0.29 | |
| 19 | 0124-054 | SNAP CAP W/WASHER | 1 | $1.23 | |
| 21 | 0623-372 | SCREW,THUMB-1/4X20X3.0 | 1 | $5.92 | |
| 23 | 0123-539 | NUT,SPEED 1/4-20 U-TYPE | 1 | $0.65 | |
| 24 | 1611-575 | DECAL,WARNING-HOOD | 1 | $25.95 | |
| 25 | 0609-171 | BULB,HEADLIGHT HB5/9007 | 1 | $65.95 | |
| 26 | 0639-963 | KIT, HEADLIGHT REPLACEMENT | 1 | $229.95 | |
| 27 | 0623-280 | SCREW,SELF TAP-HWH #8X5/8 TYPE A | 1 | $0.68 | |
| 28 | 0623-380 | SPRING,ADJUSTMENT-HEADLIGHT | 1 | $2.47 | |
| 29 | 0609-164 | CLIP,RETAINING-HEADLIGHT BULB | 1 | $20.95 | |
| 30 | 0623-362 | RIVET,PLASTIC-REINSTALLABLE | 1 | $0.68 |
