SKI, HOOD AND BELLY PAN
1978 KITTY CAT
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 8011-040 | BOLT,CRG 1/4-20X.75 GR1 Z&Y | 1 | $0.12 | |
| 3 | 0302-145 | BELLY PAN | 1 | $181.95 | |
| 4 | 8040-366 | NUT,HEX LOCK-NYL 1/4-20 Z&Y | 1 | $0.26 | |
| 5 | 8061-688 | RIVET,BLIND-LF SS66 ZINC | 1 | $0.95 | |
| 6 | 8002-130 | SCREW, CAP-HH 5/16-18 X .75 G5 Z&Y | 1 | $0.68 | |
| 7 | 8051-242 | WASHER,SPR LOCK-5/16 .314X.583X.078 Z&Y | 1 | $1.64 | |
| 9 | 0662-220 | ENGINE,60 F/C-'99KC | 1 | $1,422.95 | |
| 10 | 0302-071 | DECAL,HOOD KITTY CAT | 1 | $88.95 | |
| 12 | 0300-155 | HOOK,SPRING LATCH | 1 | $16.49 | |
| 13 | 0123-636 | SCREW,MACH TR HD 6-32X5/8 SLOT | 1 | $0.68 | |
| 15 | 0123-149 | WSHR,FLAT 11/64X3/8X.030TH Z&Y | 1 | $2.06 | |
| 16 | 0716-056 | HOOD-DRILLED | 1 | $224.95 | |
| 17 | 8041-126 | NUT,HEX THIN LOCK-NYL 6-32 Z&Y | 1 | $0.26 | |
| 19 | 0300-198 | DECAL-ARCTIC CAT,SCRIPT | 1 | $39.95 | |
| 21 | 0670-514 | CAP,GAS | 1 | $19.25 | |
| 22 | 0770-038 | TANK,GAS W/CAP | 1 | $105.95 | |
| 23 | 0610-008 | HOSE, GAS LINE-3/16X25' | 1 | $93.95 | |
| 24 | 0302-057 | FUEL FLTR & SHUT OFF | 1 | $29.95 | |
| 27 | 3004-447 | WASHER, LOCK 6MM | 1 | $3.16 | |
| 28 | 3004-849 | SCREW,M6X10 | 1 | $2.47 | |
| 30 | 8004-140 | SCREW,CAP-HH 5/16-24 X2.75 G5 Z&Y | 1 | $0.95 | |
| 32 | 0300-158 | SADDLE UPPER | 1 | $16.95 | |
| 33 | 8040-456 | NUT,HEX LOCK-NYL 5/16-24 Z&Y | 1 | $0.54 | |
| 35 | 0300-187 | COVER,SADDLE | 1 | $15.95 | |
| 37 | 8050-247 | WASHER,FLAT- 5/16 X .688 X .065 Z&Y | 1 | $0.68 | |
| 38 | 8040-396 | NUT,HEX LOCK-NYL 1/4-28 Z&Y | 1 | $0.26 | |
| 40 | 0703-128 | SKAG,KITTY CAT-PTD BLK | 1 | $30.95 | |
| 42 | 0300-189 | MOULDING,SKI TIP | 1 | $40.95 | |
| 43 | 1670-325 | GROMMET, 1/4"-FUEL TANK | 1 | $2.88 | |
| 44 | 3003-023 | WASHER, FLAT,5MM | 1 | $1.95 | |
| 45 | 8050-217 | WASHER,FLAT- 1/4 X .625 X .065 Z&Y | 1 | $0.12 | |
| 47 | 0123-425 | CLAMP HOSE 5/16 | 1 | $1.95 |
