WATER PUMP
1977 Z 340
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 3003-395 | SCREW,6X20 C/S | 1 | $3.44 | |
| 5 | 3004-280 | WASHER, LOCK,8MM | 1 | $1.95 | |
| 6 | 3423-204 | WASHER | 1 | $1.95 | |
| 10 | 3007-386 | BOLT | 1 | $3.16 | |
| 11 | 3004-447 | WASHER, LOCK 6MM | 1 | $3.16 | |
| 12 | 3003-023 | WASHER, FLAT,5MM | 1 | $1.95 | |
| 15 | 3002-234 | PULLEY,DRVN #2-WATER PUMP | 1 | $26.95 | |
| 16 | 3002-235 | SHIM M67 | 1 | $4.95 | |
| 17 | 3004-850 | BOLT,STUD-M6X16 | 1 | $2.75 | |
| 21 | 3008-488 | CLIP (ID:17.8) | 1 | $6.34 | |
| 22 | 3002-218 | UNION OUTLET BY-PASS,M16 | 1 | $22.01 |
