DRIVE TRAIN
1976 PANTHER 440
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 8040-426 | NUT,HEX LOCK-NYL 5/16-18 Z&Y | 1 | $0.40 | |
| 2 | 0602-198 | PLATE,FLANGE-BEARING (TRIANGLE) | 1 | $12.35 | |
| 3 | 1602-375 | BEARING,1.00 W/COLLAR | 1 | $72.95 | |
| 4 | 8011-132 | BOLT,CRG 5/16-18X1.0 GR1 Z&Y | 1 | $1.78 | |
| 5 | 0102-260 | SHAFT,DRIVE-SUB ASS'Y | 1 | $247.95 | |
| 6 | 8011-140 | BOLT,CRG 5/16-18X2.75 GR1 Z&Y | 1 | $0.65 | |
| 7 | 0107-233 | STUD,DROPCASE | 1 | $33.95 | |
| 8 | 1702-179 | KIT,REPLACEMENT BEARING-1" | 1 | $79.95 | |
| 9 | 0107-003 | SEAL,O RING .093 | 1 | $1.37 | |
| 11 | 0107-513 | SPROCKET-33T | 1 | $124.95 | |
| 12 | 0123-020 | CARRIAGE SPRING WASHER | 1 | $13.73 | |
| 13 | 8012-130 | SCREW, CAP -HHNLP 5/16-18X.75 G5 Z&Y | 1 | $12.35 | |
| 15 | 8053-242 | WASHER,LOCK-5/16 EXT TOOTH TYP A Z&Y | 1 | $0.12 | |
| 16 | 8002-132 | SCREW,CAP-HH 5/16-18 X1.00 G5 Z&Y | 1 | $0.95 | |
| 17 | 0623-293 | PLUG, DRAIN | 1 | $2.61 | |
| 18 | 0123-641 | WASHER,FIBER-1/2X13/16X.030 | 1 | $4.95 | |
| 21 | 8050-212 | WASHER,FLAT- 1/4 X .500 X .063 Z&Y | 1 | $0.68 | |
| 22 | 0707-026 | SPRING, TIGHTENER | 1 | $27.95 | |
| 23 | 0107-411 | PAD, TIGHTENER | 1 | $29.95 | |
| 25 | 0107-226 | PIN & LINK ASS'Y,TIGHTENER | 1 | $18.95 | |
| 27 | 8012-039 | SCREW,CAP-HHNLP 1/4-20X.625 G5 Z&Y | 1 | $0.40 | |
| 28 | 8041-426 | NUT,HEX THIN LOCK-NYL 5/16-18 Z&Y | 1 | $0.40 | |
| 30 | 0107-408 | SPROCKET-21T | 1 | $74.95 | |
| 31 | 1702-180 | KIT,REPLACEMENT BEARING-7/8" | 1 | $63.95 | |
| 35 | 0123-082 | PIN, COTTER - 1/16 X 5/8 | 1 | $0.15 | |
| 36 | 1602-290 | BEARING,1 W/LOCK(LARGE RACE) | 1 | $81.95 | |
| 38 | 0109-218 | WASHER PUCK BACKUP | 1 | $1.95 | |
| 39 | 0109-598 | PUCK,BRAKE | 1 | $22.95 | |
| 40 | 0109-597 | PUCK,BRAKE | 1 | $22.95 | |
| 41 | 8050-242 | WASHER,FLAT- 5/16 X .625 X .063 Z&Y | 1 | $2.06 | |
| 44 | 0107-314 | COLLAR,LOCK TAPER CLUTCH | 1 | $57.95 | |
| 45 | 8080-184 | SCREW,SET-HS 10-32 X 5/16 | 1 | $0.12 | |
| 47 | 0228-022 | SHAFT,DRIVEN | 1 | $135.95 | |
| 48 | 0101-076 | KEY 3/16 X 1/4 X 3 | 1 | $2.75 | |
| 49 | 0226-019 | CLUTCH DRIVEN-W/O BRK DISC | 1 | $315.95 | |
| 50 | 8050-247 | WASHER,FLAT- 5/16 X .688 X .065 Z&Y | 1 | $0.68 | |
| 50 | 0123-263 | WASHER,FLAT 1IDX1-1/2X14GA | 1 | $0.45 |
