1975 Arctic Cat PANTHER 440 — SHROUD, TAILLIGHT ASSEMBLY AND REAR BUMPER
1975 PANTHER 440
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 8060-486 | RIVET, BLIND-DH SS54 ZINC | 1 | $0.40 | |
| 4 | 0123-465 | SCREW,MTL PN HD 8X5/8 SELF TAP | 1 | $0.35 | |
| 5 | 0116-410 | LENS,TAILLIGHT | 1 | $6.95 | |
| 6 | 0109-445 | BULB,TAILLIGHT GE68 | 1 | $1.09 | |
| 7 | 0109-446 | BULB BRAKE LIGHT GE1142 | 1 | $15.11 | |
| 10 | 8060-488 | RIVET,BLIND-DH SS56 ZINC | 1 | $0.40 | |
| 16 | 0123-671 | SCREW,MACH TR HD 5/16X1-1/4 CHM | 1 | $0.15 | |
| 18 | 8070-220 | PIN,SPRING-1/8 X 3/4 SLOTTED P&O | 1 | $0.85 | |
| 20 | 8008-580 | SCREW,MACH-SLTH 1/4-20X.75 G2 Z&Y | 1 | $0.68 | |
| 21 | 0123-539 | NUT,SPEED 1/4-20 U-TYPE | 1 | $0.65 | |
| 26 | 8007-674 | SCREW,MACH-CRTH 5/16-18X1.25 G2 Z&Y | 1 | $0.12 | |
| 31 | 0116-074 | SNAP,BODY-CUSHION 61-0393-1183 | 1 | $1.64 | |
| 35 | 0123-352 | WSHR,FLAT .129/.133X5/16 X 22 GA Z&Y | 1 | $0.95 |
