1974 Arctic Cat VIP 440 — MAGNETO
1974 VIP 440
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 3001-052 | BASE | 1 | $57.95 | |
| 3 | 3001-129 | COIL,EXCITING | 1 | $149.95 | |
| 4 | 3001-130 | COIL,PULSING | 1 | $154.95 | |
| 5 | 3001-338 | COIL,LIGHTING | 1 | $205.95 | |
| 18 | 3001-063 | SPRING,PLUG CAP | 1 | $6.20 | |
| 23 | 3000-456 | SCREW 6 X 40 | 1 | $0.75 | |
| 27 | 3001-069 | GROMMET | 1 | $0.26 | |
| 33 | 3007-847 | WASHER,LOCK-4MM | 1 | $3.16 | |
| 38 | 3004-447 | WASHER, LOCK 6MM | 1 | $3.16 |
