1997 Arctic Cat 750G — RECOIL STARTER ASSEMBLY
1997 750G
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0691-638 | COWLING, VENTILATION SIDE | 1 | $8.95 | |
| 2 | 0693-403 | BOLT (M:6XL:8) | 1 | $6.95 | |
| 3 | 0693-404 | SEAL | 1 | $8.95 | |
| 4 | 0693-405 | COWLING, VENTILATION UPPER | 1 | $17.95 | |
| 5 | 0693-318 | BOLT,M6X10 | 1 | $4.29 | |
| 6 | 0693-406 | STARTER ASSY, RECOIL | 1 | $174.95 | |
| 7 | 0693-407 | REEL, STARTER | 1 | $49.95 | |
| 8 | 0693-408 | RATCHET SET | 1 | $89.95 | |
| 10 | 0691-647 | SPRING, FRICTION | 1 | $5.51 | |
| 12 | 0691-649 | SPRING, RETURN | 1 | $2.29 | |
| 13 | 0691-577 | SPRING, REWIND | 1 | $27.95 | |
| 14 | 0693-409 | PLATE, FRICTION | 1 | $21.95 | |
| 15 | 0691-305 | GRIP, STARTER | 1 | $13.95 | |
| 16 | 3006-889 | ROPE,STARTER-C.T.L(6MM DIA)(203 CM) | 1 | $27.95 | |
| 17 | 0693-241 | BOLT, M6X12 | 1 | $3.16 | |
| 18 | 0691-652 | PULLEY, STARTER | 1 | $19.95 | |
| 20 | 0691-161 | EMBLEM, ARCTCO SIDE | 1 | $17.95 | |
| 21 | 0693-969 | HARNESS,CONTROL | 1 | $711.95 | |
| 22 | 0693-039 | DECAL | 1 | $13.95 |
