2018 Arctic Cat ALTERRA 90 — EXHAUST AIR INTAKE ASSEMBLY
2018 ALTERRA 90
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3305-596 | TUBE ASSY,VACUUM | 1 | $13.73 | |
| 2 | 3304-161 | CLIP B7 TUBE | 1 | $1.37 | |
| 3 | 3305-599 | AI/C-AICV ASSY | 1 | $58.95 | |
| 4 | 3305-355 | RUBBER AICV MOUNT | 1 | $3.95 | |
| 5 | 3303-712 | CLIP BREATHER TUBE | 1 | $2.33 | |
| 6 | 3305-597 | DUCT,AICV-REED VALVE | 1 | $20.63 | |
| 7 | 3304-167 | CLAMP D18 TUBE | 1 | $3.57 | |
| 8 | 3305-598 | DUCT,AIR-AICV | 1 | $19.25 |
