2017 Arctic Cat PROWLER 500 — COOLING ASSEMBLY
2017 PROWLER 500
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 6 | 3303-349 | CLIP B10 TUBE | 1 | $0.95 | |
| 7 | 3304-163 | CLIP C11 TUBE | 1 | $1.78 | |
| 11 | 3304-587 | BOLT WASHER 6*16 | 1 | $1.23 | |
| 12 | 3303-748 | CAP COMP | 1 | $26.95 | |
| 14 | 3304-161 | CLIP B7 TUBE | 1 | $1.37 | |
| 16 | 3305-396 | NUT FLANGE 6MM | 1 | $1.09 | |
| 20 | 3305-702 | BOLT FLANGE 6*14 | 1 | $0.81 | |
| 23 | 3306-256 | CLAMP WATER HOSE | 1 | $4.82 | |
| 25 | 0813-050 | THERMOSTAT ASSY | 1 | $99.95 | |
| 26 | 0830-205 | O-RING 18.3X2 | 1 | $3.95 | |
| 27 | 0808-202 | COVER THERMOSTAT | 1 | $16.49 | |
| 28 | 3306-260 | BRKT THERMOSTAT STAY | 1 | $4.40 | |
| 29 | 3307-050 | BOLT FLANGE SH 6*25 | 1 | $2.75 | |
| 31 | 0410-310 | HOSE,COOLANT-CROSSOVER(500) | 1 | $23.39 | |
| 33 | 3305-941 | CLAMP,D28 | 1 | $6.20 | |
| 34 | 0423-098 | CLAMP,HOSE(NORMA FBS 17-12) | 1 | $2.75 |
