TRANSAXLE CASE/COVER
2016 WILDCAT TRAIL XT EPS
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0817-068 | SUBASSEMBLY, PINION | 1 | $679.95 | |
| 2 | 0817-081 | O-RING, 2-156 | 1 | $2.47 | |
| 3 | 0817-025 | SHIM SET135.00 OD X 116.0 ID | 1 | $118.95 | |
| 4 | 0817-078 | BEARING, BALL, 6208 C3 | 1 | $34.95 | |
| 5 | 0817-080 | PLUG, PINION COVER | 1 | $10.97 | |
| 6 | 0817-069 | SUBASSEMBLY, CASE | 1 | $793.95 | |
| 7 | 0817-079 | SEAL,TRIPLE LIP-1.180X1.850X0.315 VITON | 1 | $20.63 | |
| 8 | 0817-076 | SEAL,TRIPLE LIP-VITON 40X70X7 | 1 | $23.39 | |
| 9 | 0817-077 | PIN, DOWEL, 6 X 20 | 1 | $1.92 | |
| 10 | 0817-004 | SCREW, TAPPING TTH HD #10-24 X .375 | 1 | $1.64 | |
| 11 | 0817-070 | DEFLECTOR, OIL, | 1 | $2.88 | |
| 12 | 0817-028 | BEARING, BALL, 6205 C3 25X52X15 | 1 | $12.35 | |
| 13 | 0817-024 | SHIM,SET 2.040 OD X 1.63 ID | 1 | $30.95 | |
| 14 | 0817-015 | RING, RETAINING BASIC, INTERNAL 2.047 | 1 | $5.92 | |
| 15 | 0817-023 | SHIM,SET 1.180 OD X .995 ID | 1 | $60.95 | |
| 16 | 0817-012 | RING, RETAINING BASIC, EXTERNAL .984 | 1 | $2.61 | |
| 17 | 0817-011 | PIN, DOWEL, 10X45 | 1 | $4.26 | |
| 20 | 0817-072 | SEAL, TRIPLE LIP, 0.984X2.047X0.394 | 1 | $10.97 | |
| 21 | 0817-040 | COVER, MACH | 1 | $230.95 | |
| 22 | 0817-065 | PLUG, DETENT | 1 | $12.35 | |
| 23 | 0817-075 | O-RING, .530 I.D X .082 WIDE | 1 | $1.50 | |
| 24 | 0817-036 | SPRING, COMPRESSION, .450 OD X 1.58 | 1 | $2.47 | |
| 25 | 0817-051 | TUBE, VENT, 90 -1/4" HOSE | 1 | $4.40 | |
| 26 | 0409-151 | R/B 0409-202 | 1 | $82.95 | |
| 27 | 0817-037 | SPRING, WAVE, 16 X 11.28 X 0.25 | 1 | $10.97 | |
| 28 | 0817-019 | RING, RETAINING, EXTERNAL DSH-12 | 1 | $4.95 | |
| 29 | 0817-067 | SUBASSEMBLY, BELLCRANK | 1 | $41.95 | |
| 30 | 0817-007 | NUT, LOCK HEX FLANGE, NYLON M8 X 1.25 | 1 | $1.92 | |
| 31 | 0430-121 | SENSOR,SPEED-LOR MX | 1 | $43.95 | |
| 32 | 0817-006 | SCREW, HEX FLANGE HEAD, M6 X 1 X 20 | 1 | $1.92 | |
| 33 | 0817-003 | PLUG, M18 X 1.5, MAGNETIC | 1 | $12.35 | |
| 34 | 0817-002 | PLUG, M18 X 1.5 | 1 | $6.83 | |
| 35 | 0817-005 | SCREW, HEX FLANGE HEAD, M8 X 1.25 X 30 | 1 | $1.64 |
