WINCH ASSEMBLY
2016 TRV 700 EPS SE /
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0409-165 | WINCH,V3000-DOM | 1 | $638.95 | |
| 2 | 1441-831 | CABLE,WINCH | 1 | $69.95 | |
| 3 | 0623-038 | NUT,HEX M6 Z&Y-SEMS (W/WASHER) | 1 | $0.26 | |
| 4 | 8051-246 | WASHER,SPR LOCK-5/16 .314X.593X.097 Z&C | 1 | $0.68 | |
| 5 | 8408-820 | SCREW,CAP-HFH M8X1.25X20 CL8.8 Z&Y | 1 | $0.68 | |
| 6 | 0441-403 | FAIRLEAD,ROLLER-1600 (B) | 1 | $35.95 | |
| 7 | 0411-474 | DECAL,WARNING-ROLLER FAIRLEAD | 1 | $212.95 | |
| 8 | 8468-820 | SCREW,MACH-TSPNH M8X1.25X20 CL8.8 BLK | 1 | $1.50 | |
| 9 | 1441-781 | STRAP,WCH HOOK-"ARCTIC CAT"(RB 3441-150) | 1 | $6.95 | |
| 10 | 1441-833 | HOOK,WINCH | 1 | $42.95 | |
| 11 | 1441-834 | PIN | 1 | $3.57 | |
| 12 | 0623-175 | PIN,COTTER 3/32 X 1 | 1 | $0.40 | |
| 13 | 0123-903 | TIE,CABLE 11.50 | 1 | $0.54 | |
| 14 | 0445-068 | CABLE, WINCH-SOLENOID (7" YEL #6) | 1 | $10.97 | |
| 15 | 0445-107 | CABLE,WINCH-SOLENOID(10" BLU #6 FERRITE) | 1 | $20.63 | |
| 16 | 1441-112 | CABLE,BATTERY-SOLENOID (75" BLK #6) | 1 | $64.95 | |
| 17 | 0445-087 | CABLE,BATTERY-SOLENOID (75" RED #6) | 1 | $64.95 | |
| 18 | 0645-019 | BOOT,TERMINAL-BATTERY | 1 | $4.40 | |
| 19 | 0409-066 | R/B 0409-246 | 1 | $139.95 | |
| 20 | 8476-625 | SCREW,MACH-TSTRH M6X1.0X25 Z&Y | 1 | $1.78 | |
| 21 | 0409-087 | SWITCH,WINCH-HARNESS ASSY | 1 | $54.95 | |
| 22 | 0409-034 | HOLDER, SWITCH-WINCH (500 A) | 1 | $10.97 | |
| 23 | 8464-560 | SCREW,MACH-PHTRH M5-.8X60 Z&BLK | 1 | $12.35 | |
| 24 | 0423-593 | WASHER,FLAT-Z&B (11MM ODX 5.5MM IDX 1.8) | 1 | $0.95 | |
| 25 | 0423-382 | SCREW, COVER-WINCH SWITCH | 1 | $0.68 | |
| 26 | 5506-053 | COVER,WINCH SWITCH-BLACK | 1 | $16.49 |
