DRIVE TRAIN ASSEMBLY
2016 ALTERRA 550
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 0410-070 | HOSE,FUEL-25 FT (0419-272 CTL) | 1 | $66.95 | |
| 3 | 0423-404 | SCREW,CAP-HFH M10X1.25X120 CL10.9 Z&Y | 1 | $3.30 | |
| 4 | 8428-002 | NUT,HEX FLG- CLINCH LOCK- M10-1.25 Z&Y | 1 | $5.09 | |
| 5 | 1423-255 | SPACER,GEARCASE | 1 | $3.57 | |
| 6 | 0423-576 | SCREW,CAP-HFH M10-1.25X130 | 1 | $8.21 | |
| 7 | 2402-200 | BOOT,DRIVESHAFT | 1 | $10.97 | |
| 8 | 1402-026 | SPRING | 1 | $1.92 | |
| 9 | 2402-193 | FLANGE,OUTPUT | 1 | $82.95 | |
| 10 | 8408-820 | SCREW,CAP-HFH M8X1.25X20 CL8.8 Z&Y | 1 | $0.68 | |
| 11 | 2402-175 | SHAFT,PROPELLER-FRONT | 1 | $47.95 | |
| 12 | 0830-240 | O-RING-#2-124 | 1 | $3.57 | |
| 13 | 0423-393 | CLAMP,42mm DIA - BOOT | 1 | $4.40 | |
| 14 | 0402-985 | BOOT,COUPLER (TBX) | 1 | $6.75 | |
| 15 | 0423-411 | CLAMP,30MM-BOOT | 1 | $4.26 | |
| 16 | 0673-618 | BUMPER,DRIVESHAFT | 1 | $3.57 | |
| 17 | 2402-173 | SHAFT,PROPELLER-REAR | 1 | $64.95 | |
| 18 | 2502-153 | GEARCASE,REAR-ASSEMBLY-3.1 | 1 | $1,316.95 | |
| 19 | 1423-179 | SPACER,STL-10.5ID X 25.4OD X 19.5LG | 1 | $6.20 | |
| 20 | 1423-266 | SCREW,CAP-HFH M10-1.25X155 | 1 | $6.47 | |
| 21 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 |
