FRONT SUSPENSION ASSEMBLY
2015 XC 450 EFI
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3306-775 | CUSHION ASSY,FR (WHITE) | 1 | $268.95 | |
| 2 | 3303-376 | SCREW,CAP-HFH M10X1.25X40 | 1 | $2.06 | |
| 3 | 3304-031 | NUT U 10MM | 1 | $2.61 | |
| 4 | 3306-564 | A-ARM,FRONT-UPPER-RH-ASSY (SILVER) | 1 | $309.95 | |
| 4 | 3306-565 | A-ARM FRONT-UPPER-LH-ASSY (SILVER) | 1 | $309.95 | |
| 5 | 3313-111 | SLEEVE,SUSPENSION | 1 | $16.49 | |
| 6 | 3313-112 | BUSHING,SUSPENSION | 1 | $2.33 | |
| 7 | 3313-113 | SEAL,SUSPENSION | 1 | $3.44 | |
| 8 | 0423-009 | CLIP,BALL JOINT | 1 | $1.37 | |
| 9 | 0405-483 | BALLJOINT-ASSY (DOUBLE STAKE) | 1 | $38.95 | |
| 10 | 3313-430 | SCREW,CAP-HFH M10 X 1.25 | 1 | $16.49 | |
| 11 | 3304-183 | SCREW,CAP-HFH M10X1.25X85 | 1 | $2.59 | |
| 12 | 3306-566 | A-ARM ASSY FRONT LWR RH (SILVER) | 1 | $309.95 | |
| 12 | 3306-567 | A-ARM ASSY FRONT LWR LH (SILVER) | 1 | $309.95 | |
| 13 | 3313-107 | SLEEVE,SUSPENSION | 1 | $12.35 | |
| 14 | 3306-456 | GUARD R BOOT | 1 | $16.49 | |
| 14 | 3306-457 | GUARD,L BOOT | 1 | $16.49 | |
| 15 | 3304-587 | BOLT WASHER 6*16 | 1 | $1.23 | |
| 16 | 3313-831 | HALFSHAFT,FRONT | 1 | $567.95 | |
| 17 | 3313-560 | DIFF SIDE BOOT SERVICE KIT(IN BOARD) | 1 | $94.95 | |
| 19 | 3313-558 | WHEEL SIDE BOOT SERVICE KIT-OUT BOARD | 1 | $69.29 | |
| 20 | 3323-130 | KNUCKLE,STEERING-RH ASSY | 1 | $248.95 | |
| 20 | 3323-131 | KNUCKLE,STEERING-LH ASSY | 1 | $248.95 | |
| 21 | 1402-809 | BEARING,WHEEL | 1 | $33.95 | |
| 22 | 0423-423 | RING,RETAINING (HOUSING ID:55) | 1 | $4.13 | |
| 23 | 3323-127 | SCREW-SHOULDER TSPH M6-1.0X18MM | 1 | $4.13 |
