2015 Arctic Cat WILDCAT SPORT XT — FRONT AND SIDE PANEL ASSEMBLIES
2015 WILDCAT SPORT XT
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 4406-263 | FASCIA,FRONT | 1 | $33.95 | |
| 2 | 0423-609 | SCREW,MACH-TSPNWH M6X1.0X23.5 BLK | 1 | $0.95 | |
| 3 | 4406-269 | PANEL,HOOD-BLACK | 1 | $82.95 | |
| 4 | 4411-433 | DECAL,CREST (VB) | 1 | $10.97 | |
| 4 | 4411-435 | DECAL,CREST (VRM) | 1 | $10.97 | |
| 5 | 4411-434 | DECAL,HOOD (VB) | 1 | $50.95 | |
| 5 | 4411-444 | DECAL,HOOD (VRM) | 1 | $50.95 | |
| 6 | 5506-822 | FENDER,FRONT-RH NEPTUNE BLUE | 1 | $249.95 | |
| 6 | 5506-823 | FENDER,FRONT-LH NEPTUNE BLUE | 1 | $249.95 | |
| 6 | 5506-818 | FENDER,FRONT-RH VIBRANT RED | 1 | $249.95 | |
| 6 | 5506-819 | FENDER,FRONT-LH VIBRANT RED | 1 | $249.95 | |
| 7 | 1423-198 | SCREW,MACH-TSBWH M6X 1.0 TRILOBE BLK | 1 | $0.95 | |
| 8 | 0623-362 | RIVET,PLASTIC-REINSTALLABLE | 1 | $0.68 | |
| 9 | 0423-577 | CLIP,U-NUT M6 | 1 | $0.40 | |
| 10 | 4406-280 | PANEL,LOWER SIDE-RH BLACK | 1 | $42.95 | |
| 10 | 4406-281 | PANEL,LOWER SIDE-LH BLACK | 1 | $42.95 | |
| 11 | 4411-436 | DECAL,SIDE LWR FR-RH (VB) | 1 | $33.95 | |
| 11 | 4411-437 | DECAL,SIDE LWR FR-LH (VB) | 1 | $33.95 | |
| 11 | 4411-446 | DECAL,SIDE LWR FR-RH (VRM) | 1 | $33.95 | |
| 11 | 4411-447 | DECAL,SIDE LWR FR-LH (VRM) | 1 | $33.95 | |
| 13 | 4411-438 | DECAL,SIDE LWR RR 'XT'-RH (VB) | 1 | $50.95 | |
| 13 | 4411-439 | DECAL,SIDE LWR RR 'XT'-LH (VB) | 1 | $50.95 | |
| 13 | 4411-448 | DECAL,SIDE LWR RR 'XT'-RH (VRM) | 1 | $50.95 | |
| 13 | 4411-449 | DECAL,SIDE LWR RR 'XT'-LH (VRM) | 1 | $50.95 | |
| 14 | 0623-544 | PLUG, CHRISTMAS TREE | 1 | $0.54 |
