FRONT DOOR ASSEMBLY
2015 WILDCAT 4X LTD
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 2436-260 | KIT,LATCH-DOOR-FR-RH-ASSY(WC X LTD) | 1 | $197.95 | |
| 1 | 2436-261 | KIT,LATCH-DOOR-FR-LH-ASSY (WC X LTD) | 1 | $197.95 | |
| 2 | 1423-235 | SPRING,LATCH HANDLE | 1 | $4.54 | |
| 3 | 1423-231 | SCREW,BUTTON HEAD TORX BLK M6X1.0X30 | 1 | $2.61 | |
| 4 | 4406-999 | HANDLE,DOOR | 1 | $19.25 | |
| 5 | 1423-153 | HEX NYLON NUT CL8 BLK ZINC M6(DIN 985) | 1 | $0.95 | |
| 6 | 4406-452 | BRKT,DOOR LATCH-RH | 1 | $26.95 | |
| 6 | 4406-453 | BRKT,DOOR LATCH-LH | 1 | $26.95 | |
| 7 | 8468-616 | SCREW,MACH-TSPNH M6X1.0X16 CL8.8 BLK | 1 | $0.68 | |
| 8 | 4406-908 | LATCH,ROTARY (50203) | 1 | $101.95 | |
| 8 | 4406-909 | LATCH,ROTARY (50202) | 1 | $82.95 | |
| 9 | 8051-213 | R/B 8051-212 | 1 | $0.35 | |
| 10 | 1423-232 | SCREW,BUTTON HEAD TORX BLK M6X1.0X40 | 1 | $3.02 | |
| 11 | 1423-171 | NUT,FLG LOCK-NYLON SL M6-1.0 CL8 Z&B | 1 | $1.23 | |
| 12 | 4406-447 | HINGE,WELDT-2 | 1 | $34.95 | |
| 12 | 4406-446 | HINGE,WELDT-1 | 1 | $27.95 | |
| 13 | 0423-817 | SCREW,MACH-TSTRH M8X1.25X20 CL8.8 W/LOCK | 1 | $1.50 | |
| 14 | 1423-224 | BUSHING,DOOR HINGE | 1 | $5.23 | |
| 15 | 5506-490 | HINGE,MAIN WELDT-RH | 1 | $116.95 | |
| 15 | 5506-491 | HINGE,MAIN WELDT-LH | 1 | $116.95 | |
| 16 | 0826-029 | SCREW,MACH-TSPH M6 X1X12 W/ THD LOCK | 1 | $0.68 | |
| 17 | 4406-450 | STRIKER,DOOR-RH | 1 | $26.95 | |
| 17 | 4406-451 | STRIKER,DOOR-LH | 1 | $26.95 | |
| 18 | 1423-264 | WASHER,FLAT-18X6.4X1.6-BLK | 1 | $1.09 | |
| 19 | 1423-263 | NUT,HEX ACORN M6-1.0 BLK | 1 | $2.06 | |
| 20 | 5506-488 | FRAME,DOOR-RH-BLK | 1 | $504.95 | |
| 20 | 5506-489 | FRAME,DOOR-LH-BLK | 1 | $409.95 | |
| 21 | 1423-234 | CAP,PLASTIC-1.25" TUBE | 1 | $1.92 | |
| 22 | 1423-233 | BOLT,CARRIAGE CL8.8 BLK M6X1.0X16 | 1 | $1.78 | |
| 23 | 4406-455 | TRIM,DOOR SEAL | 1 | $42.95 | |
| 24 | 0518-212 | DOOR,PANEL W/ DECALS-MW-FRT-RH(WC 4X LTD | 1 | $341.95 | |
| 24 | 0518-213 | DOOR,PANEL W/ DECALS-MW-FRT-LH(WC 4X LTD | 1 | $341.95 | |
| 24 | 0518-216 | DOOR,PANEL W/ DECALS-MB-FRT-RH(WC 4X LTD | 1 | $341.95 | |
| 24 | 0518-217 | DOOR,PANEL W/ DECALS-MB-FRT-LH(WC 4X LTD | 1 | $341.95 | |
| 25 | 4406-444 | PANEL,DOOR SKIN-RH-BLK | 1 | $281.95 | |
| 25 | 0518-244 | DOOR,PANEL W/ WARNING DECAL-18 PSI-LH | 1 | $341.95 | |
| 25 | 4406-445 | PANEL,DOOR SKIN-LH-BLK | 1 | $281.95 | |
| 26 | 4411-105 | DECAL,WARNING-TIRE PRESSURE (18 PSI) | 1 | $10.97 | |
| 27 | 4411-588 | DECAL,DOOR FR-RH-(VR) | 1 | $203.95 | |
| 27 | 4411-589 | DECAL,DOOR FR-LH-(VR) | 1 | $203.95 | |
| 27 | 4411-600 | DECAL,DOOR FR-RH-(MATTE BLK) | 1 | $203.95 | |
| 27 | 4411-601 | DECAL,DOOR FR-LH-(MATTE BLK) | 1 | $203.95 |
