TRANSMISSION ASSEMBLY
2015 90 2X4 DVX
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3303-307 | R/B 3307-202 | 1 | $0.65 | |
| 2 | 3303-108 | PLATE A2 FIXING **6000 C.97.09.18. | 1 | $2.33 | |
| 3 | 3305-814 | SPROCKET,DRIVE | 1 | $50.95 | |
| 4 | 3305-820 | CHAIN,DRIVE (72L) | 1 | $86.95 | |
| 5 | 3305-805 | SHAFT, FINAL | 1 | $163.95 | |
| 6 | 3305-822 | SHAFT,COMP COUNTER | 1 | $163.95 | |
| 7 | 3305-809 | SHAFT,MAIN | 1 | $85.95 | |
| 8 | 3304-042 | WASHER THRUST 20MM | 1 | $1.78 | |
| 9 | 3305-811 | GEAR,REVERSE | 1 | $129.95 | |
| 10 | 3304-074 | BRG NEEDLE 20*26*16 | 1 | $23.39 | |
| 11 | 3305-812 | WASHER,SPLINE 20MM | 1 | $2.06 | |
| 12 | 3303-344 | CIR CLIP EX/20MM | 1 | $1.37 | |
| 13 | 3305-029 | GEAR, SELECT-SLIDING | 1 | $85.95 | |
| 14 | 3303-275 | WASHER THRUST 15MM | 1 | $1.09 | |
| 15 | 3305-810 | GEAR,FORWARD | 1 | $112.95 | |
| 16 | 3305-024 | BUSH 15MM | 1 | $9.59 | |
| 17 | 3305-028 | COLLAR 15*20*11 | 1 | $13.73 | |
| 18 | 3303-588 | WASHER SPEIAL 12MM | 1 | $1.78 | |
| 19 | 3305-813 | SHAFT,DRIVE | 1 | $163.95 | |
| 20 | 3306-008 | GEAR DRUM SHIFT | 1 | $33.95 | |
| 21 | 3306-007 | ROLLER 3.5X11.5 | 1 | $3.30 | |
| 22 | 3304-513 | SHAFT GEAR SHIFT FORK GUIDE | 1 | $6.47 | |
| 23 | 3305-815 | FORK,GEAR SHIFT | 1 | $79.95 | |
| 24 | 3306-006 | DRUM,GEAR SHIFT | 1 | $187.95 | |
| 25 | 3304-176 | BOLT FLANGE 8*28 | 1 | $1.50 | |
| 26 | 3304-652 | BOLT WASHER 6*12 | 1 | $1.09 | |
| 27 | 3305-825 | BRACKET,SHIFT GUIDE | 1 | $6.47 | |
| 28 | 3304-900 | OIL SEAL 14*24*5 | 1 | $3.02 | |
| 29 | 3305-817 | SPINDLE ASSY,DRUM SHIFT | 1 | $79.95 | |
| 30 | 3304-153 | E RING 12 | 1 | $1.92 | |
| 31 | 3303-815 | GEAR CHANGE HANDLE | 1 | $17.87 | |
| 32 | 3305-818 | SPRING,GEAR SHIFT RETURN | 1 | $4.40 | |
| 33 | 3304-036 | WASHER THRUST 14*28*2 | 1 | $1.50 |
