BODY PANEL AND HEADLIGHT ASSEMBLY

2015 300 DVX

Scroll / pinch to zoom · drag to pan · double-click resets

#	Part No.	Description	Qty	Price
1	3306-891	BODY MAIN (LIME GRN) W/ DECALS	1	$421.95
2	2411-256	DECAL,TIRE PRESSURE/PASSENGER	1	$3.30
3	4411-479	EMBLEM,AIRCAT	1	$5.95
4	4411-322	DECAL,TANK-RH (DVX 300)	1	$26.95
4	4411-323	DECAL,TANK-LH (DVX 300)	1	$50.95
5	3304-587	BOLT WASHER 6*16	1	$1.23
6	3303-232	RUBBER REAR FENDER	1	$1.92
7	3304-057	CLIP FENDER	1	$1.92
8	3304-339	STAY START MAG SW	1	$29.95
9	3304-029	BOLT WASH 5*16	1	$0.81
10	3306-111	COVER ASSY,TANK (BLACK W/DECALS)	1	$37.95
11	1411-109	DECAL,WARNING-REVERSE	1	$10.97
12	1411-577	DECAL,WARNING-OFF ROAD ONLY	1	$50.95
13	3304-381	GUIDE COVER CHANGE HANDLE	1	$16.49
14	3304-650	SCREW TAPPING 5*16 (CIRCLE HEAD)	1	$1.50
15	3304-418	NUT STAMPED	1	$1.23
16	3304-383	PANEL R TRIM (BLACK)	1	$13.73
16	3304-517	PANEL TRIM LH-BLACK	1	$5.37
17	3306-200	FENDER ASSY,R FRONT (LIME W/DECALS)	1	$82.95
17	3306-201	FENDER ASSY,L FRONT (LIME W/DECALS)	1	$82.95
18	1411-804	DECAL,WARNING-AGE (16)	1	$4.95
19	1411-932	DECAL,WARNING-GENERAL	1	$12.35
21	3304-431	NUT LOCK	1	$1.23
22	3304-432	WASHER PLAIN 7MM	1	$0.81
23	3304-683	CLIP FENDER MOUNTNG	1	$3.02
24	3304-406	BOLT SPECIAL 6*16	1	$1.78
25	3304-404	BOLT SPECIAL 6*16	1	$1.78
26	3306-050	MUDGUARD,R FLOOR	1	$50.95
26	3306-051	MUDGUARD,L FLOOR	1	$50.95
27	3304-394	FENDER R REAR (LIME)	1	$58.95
27	3304-398	FENDER L REAR (LIME)	1	$58.95
28	4411-324	DECAL,FENDER-REAR-RH (DVX 300)	1	$58.95
28	4411-325	DECAL,FENDER-REAR-LH (DVX 300)	1	$58.95
29	0411-814	DECAL,"ARCTIC CAT"-WHT	1	$50.95
30	3304-280	LIGHT ASSY R HEAD	1	$203.95
31	3304-282	SOCKET COMP	1	$37.95
32	3303-846	BULB HEAD LIGHT	1	$42.95
33	3304-281	UNIT HEAD LIGHT	1	$180.95
