REAR BODY, RACK, AND TAILLIGHT ASSEMBLY
2014 400 CR
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3306-759 | RACK,REAR-ASSEMBLY | 1 | $272.95 | |
| 2 | 1411-682 | DECAL,WARNING RACK (150LB) | 1 | $17.87 | |
| 3 | 8410-830 | SCREW,CAP-HFH M8X1.25X30 CL8.8 RIE BLK | 1 | $1.09 | |
| 4 | 0423-669 | SPACER,STEEL | 1 | $1.37 | |
| 5 | 0423-465 | GROMMET,RUBBER-12.7X23.8125 | 1 | $3.16 | |
| 6 | 3304-668 | NUT FLANGE 8MM | 1 | $0.81 | |
| 7 | 3313-522 | BOLT,M8*25 | 1 | $1.78 | |
| 8 | 3304-543 | BOLT FLANGE 8*16 | 1 | $1.50 | |
| 9 | 3313-449 | TUBE,MOUNT-RACK-REAR-PAINTED | 1 | $30.95 | |
| 10 | 3313-352 | BRACKET,RACK MOUNT-PAINTED BLACK(RH) | 1 | $13.73 | |
| 10 | 3313-353 | BRACKET,RACK MOUNT-PAINTED BLACK(LH) | 1 | $13.73 | |
| 11 | 3306-409 | FENDER,REAR (MARSH) W/DECALS | 1 | $366.95 | |
| 11 | 3306-305 | FENDER,REAR (RED) W/DECALS | 1 | $366.95 | |
| 12 | 3304-774 | NUT FLANGE 5MM(G) | 1 | $0.81 | |
| 13 | 3313-360 | REFLECTOR,REAR (OVAL) | 1 | $13.73 | |
| 14 | 1411-809 | DECAL,WARNING-PASSENGER | 1 | $3.30 | |
| 15 | 1411-893 | DECAL,TIRE PRESSURE | 1 | $26.95 | |
| 16 | 3313-362 | SHIELD,RH | 1 | $10.97 | |
| 17 | 3313-363 | SHIELD,LH | 1 | $10.97 | |
| 18 | 2411-465 | DECAL,"ARCTIC CAT" | 1 | $5.65 | |
| 19 | 3305-783 | BOLT WASHER 8*16 | 1 | $3.02 | |
| 20 | 3313-760 | FOOTWELL FRONT-RH | 1 | $47.95 | |
| 20 | 3313-761 | FOOTWELL FRONT-LH | 1 | $47.95 | |
| 21 | 3304-431 | NUT LOCK | 1 | $1.23 | |
| 22 | 3305-703 | SCREW SPECIAL 6*20 | 1 | $1.78 | |
| 23 | 3304-586 | BOLT WASHER 6*20 | 1 | $1.23 | |
| 24 | 5506-497 | FOOTPEG,BLACK | 1 | $16.49 | |
| 25 | 0423-545 | SCREW,BODY-SELF TAP #12 X 3/4 A Z&B | 1 | $1.09 | |
| 26 | 3313-762 | FOOTWELL REAR RH | 1 | $82.95 | |
| 26 | 3313-763 | FOOTWELL REAR LH | 1 | $82.95 | |
| 27 | 3305-852 | WASHER,PLAIN 6MM | 1 | $0.81 | |
| 28 | 3304-029 | BOLT WASH 5*16 | 1 | $0.81 | |
| 29 | 3313-382 | ASSY,TAILLIGHT - RH (SAE) | 1 | $102.95 | |
| 29 | 3313-383 | ASSY,TAILLIGHT - LH (SAE) | 1 | $102.95 | |
| 30 | 3313-508 | BULB,BACKUP(R5W -12V 5W) (CLEAR) | 1 | $6.75 | |
| 31 | 3313-499 | ASSY, SOCKET-TAILLIGHT (SAE) | 1 | $47.95 | |
| 32 | 3303-849 | BULB TAIL & STOP 12V21W/5W | 1 | $12.35 | |
| 33 | 3304-061 | NUT CLIP 5MM | 1 | $2.33 |
