FRONT SUSPENSION ASSEMBLY
2014 300 2X4 UTILITY
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3303-964 | ARM ASSY R UP SWING (BLACK) | 1 | $187.95 | |
| 1 | 3303-967 | ARM ASSY L UP SWING (BLACK) | 1 | $187.95 | |
| 2 | 3304-090 | OIL SEAL 18*26*4 | 1 | $4.13 | |
| 3 | 3304-689 | COLLAR SWING ARM | 1 | $13.73 | |
| 4 | 3304-199 | BEARING BALL RADIAL 6000 | 1 | $20.63 | |
| 5 | 3304-031 | NUT U 10MM | 1 | $2.61 | |
| 6 | 3304-182 | BOLT FLANGE 10*57 | 1 | $2.33 | |
| 7 | 3303-376 | SCREW,CAP-HFH M10X1.25X40 | 1 | $2.06 | |
| 8 | 3303-930 | KNUCKLE ASSY R STRG | 1 | $220.95 | |
| 8 | 3303-932 | KNUCKLE ASSY L STRG | 1 | $220.95 | |
| 9 | 3306-889 | CUSHION ASSY FR (BLACK) | 1 | $203.95 | |
| 10 | 3304-595 | BOLT FLANGE 10*50 | 1 | $2.61 | |
| 11 | 3303-966 | ARM ASSY R LOW SWING (BLACK) | 1 | $220.95 | |
| 11 | 3303-968 | ARM ASSY LEFT LOW SWING (BLACK) | 1 | $187.95 | |
| 12 | 3303-335 | WASHER PLAIN 12*26*2.3 | 1 | $0.81 | |
| 13 | 3303-328 | NUT CASTLE 12MM | 1 | $3.57 | |
| 14 | 3303-470 | PIN SPLIT 3.0*25 30251 CPN | 1 | $1.37 | |
| 15 | 3303-920 | GUARD BRAKE DISK | 1 | $9.59 | |
| 16 | 3303-356 | BOLT FLANGE 6*10 | 1 | $0.81 |
