2011 Arctic Cat 450 EFI — REAR RACK, BODY PANEL, AND FOOTWELL ASSEMBLIES
2011 450 EFI
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 2506-124 | RACK,REAR W/FENCE-ASSEMBLY | 1 | $405.95 | |
| 2 | 0411-648 | DECAL,WARNING-REAR RACK (200 LB.) | 1 | $3.30 | |
| 3 | 0441-592 | BUSHING,RACK FRAME | 1 | $4.26 | |
| 4 | 8410-830 | SCREW,CAP-HFH M8X1.25X30 CL8.8 RIE BLK | 1 | $1.09 | |
| 5 | 0423-669 | SPACER,STEEL | 1 | $1.37 | |
| 6 | 0423-465 | GROMMET,RUBBER-12.7X23.8125 | 1 | $3.16 | |
| 7 | 8432-802 | NUT,HEX-THK NYL M8X1.25 CL10 Z&Y | 1 | $0.68 | |
| 8 | 0423-654 | SCREW,SHOULDER-HFH M6-1.0 X 18 CL8.8 BLK | 1 | $1.37 | |
| 9 | 8050-222 | WASHER,FLAT- 1/4 X .734 X .063 Z&Y | 1 | $0.68 | |
| 10 | 0423-540 | NUT,FLANGE-LOCK-M6 | 1 | $0.95 | |
| 11 | 0411-965 | DECAL,"SPEEDRACK"(MRP) | 1 | $3.30 | |
| 12 | 2406-428 | FOOTWELL,AUTO-RH | 1 | $217.95 | |
| 12 | 2516-385 | R/B 8506-753 | 1 | $95.95 | |
| 13 | 0423-419 | SCREW,MACH-TSTRH-M6-1.0 X 16 BLACK | 1 | $0.95 | |
| 14 | 5506-497 | FOOTPEG,BLACK | 1 | $16.49 | |
| 15 | 0423-355 | SCREW, SHOULDER-M6-1.0 X 18-BLK | 1 | $0.95 | |
| 16 | 8424-602 | NUT,HEX-FLG M6X1.0 CL8 Z&Y | 1 | $0.26 | |
| 17 | 2506-375 | FENDER,ASSEMBLY-REAR (MARSH GREEN) | 1 | $720.95 | |
| 17 | 2506-373 | FENDER,ASSEMBLY-REAR (RED) | 1 | $742.95 | |
| 17 | 2516-920 | FENDER,REAR-ARCTIC ICE-ASSY | 1 | $969.95 | |
| 17 | 2516-726 | FENDER,REAR-A.T. HD CAMO-ASSY | 1 | $1,048.95 | |
| 17 | 2506-374 | FENDER,ASSEMBLY-REAR (LIME GREEN) | 1 | $720.95 | |
| 18 | 1411-598 | REFLECTOR,REAR-RH | 1 | $5.37 | |
| 18 | 1411-599 | REFLECTOR,REAR-LH | 1 | $5.37 | |
| 19 | 2411-143 | DECAL,TIRE PRESSURE (FIS) | 1 | $3.02 | |
| 20 | 0412-351 | HEAT SHIELD,BATTERY BOX | 1 | $4.40 | |
| 21 | 1411-809 | DECAL,WARNING-PASSENGER | 1 | $3.30 | |
| 22 | 2411-295 | DECAL,REAR (B-BODY UTILITY) | 1 | $33.95 | |
| 22 | 2411-310 | DECAL,FRT/RR-ARCTIC CAT (A & BBODY CAMO) | 1 | $16.49 | |
| 23 | 2411-304 | DECAL,REAR-UPPER SIDE-RH (BB UTLY) | 1 | $15.11 | |
| 23 | 2411-305 | DECAL,REAR UPPER SIDE-LH (BB UTLY) | 1 | $15.11 | |
| 23 | 2411-318 | DECAL,REAR SIDE-450-RH (BB CAMO) | 1 | $19.25 | |
| 23 | 2411-319 | DECAL,REAR SIDE-450-LH (BB CAMO) | 1 | $19.25 | |
| 24 | 2411-316 | DECAL,REAR SIDE-450-RH (BB UTLY) | 1 | $15.11 | |
| 24 | 2411-317 | DECAL,REAR SIDE-450-LH (BB UTLY) | 1 | $15.11 | |
| 25 | 2411-314 | DECAL,REAR-LOWER SIDE-GREEN-RH (BB) | 1 | $42.95 | |
| 25 | 2411-315 | DECAL,REAR-LOWER SIDE-GREEN-LH (BB) | 1 | $42.95 | |
| 25 | 2411-312 | DECAL,REAR-LOWER SIDE-RED-RH (BB) | 1 | $42.95 | |
| 25 | 2411-313 | DECAL,REAR-LOWER SIDE-RED-LH (BB) | 1 | $42.95 | |
| 25 | 2411-328 | DECAL,REAR-LOWER SIDE-AC ICE-RH (BB) | 1 | $16.49 | |
| 25 | 2411-329 | DECAL,REAR-LOWER SIDE-AC ICE-LH (BB) | 1 | $16.49 | |
| 25 | 2411-322 | DECAL,REAR-LOWER SIDE-LIME-RH (BB) | 1 | $42.95 | |
| 25 | 2411-323 | DECAL,REAR-LOWER SIDE-LIME-LH (BB) | 1 | $42.95 |
