TRANSMISSION ASSEMBLY
2011 1000 H2 EFI MUD PRO
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0823-301 | PULLEY, DRIVEN, 35DEG - ASSEMBLY | 1 | $769.95 | |
| 2 | 0823-176 | SHOE,CAM-DRIVEN PULLEY | 1 | $20.63 | |
| 3 | 0823-177 | SCREW,CAM SHOE | 1 | $2.06 | |
| 4 | 0823-178 | R/B 0823-457 | 1 | $18.95 | |
| 5 | 0832-010 | BEARING,CONRAD-SC03A78C3 | 1 | $66.95 | |
| 6 | 0830-176 | SEAL,CAN,47X16X5.5 | 1 | $20.63 | |
| 7 | 0823-020 | RETAINER, BEARING | 1 | $17.87 | |
| 8 | 0826-031 | SCREW,MACH-TSFH M6 X1X12 W/ THD LOCK | 1 | $1.23 | |
| 9 | 0827-010 | NUT,HEX COUNTERSUNK (M20x1.5) | 1 | $5.95 | |
| 10 | 0828-106 | WASHER, CLUTCH PLATE | 1 | $3.44 | |
| 11 | 0823-276 | PLATE,MOVABLE DRIVE-Z- | 1 | $26.95 | |
| 12 | 0823-010 | R/B 0823-277 | 1 | $6.95 | |
| 13 | 0823-265 | R/B 0823-358 | 1 | $87.95 | |
| 14 | 0823-298 | ROLLER,MOVABLE DRIVE(BLACK) 33.25G | 1 | $6.34 | |
| 15 | 0823-273 | SHEAVE,MOVABLE DRIVE-ASM-Z- | 1 | $185.95 | |
| 16 | 0823-231 | BELT,DRIVE | 1 | $176.95 | |
| 17 | 0823-156 | R/B 0823-272 | 1 | $236.95 | |
| 18 | 0823-015 | SPACER, FIXED DRIVE | 1 | $58.95 | |
| 19 | 0470-531 | O-RING,INTAKE MANIFOLD | 1 | $3.16 | |
| 20 | 0830-244 | SEAL,OIL (52X70X8) | 1 | $16.49 | |
| 21 | 0832-009 | BEARING,CONRAD-6208RUEF- 1 | 1 | $90.95 | |
| 22 | 0823-365 | R/B 0823-556 | 1 | $342.95 | |
| 23 | 0826-029 | SCREW,MACH-TSPH M6 X1X12 W/ THD LOCK | 1 | $0.68 | |
| 24 | 0822-010 | RETAINER, BEARING | 1 | $3.16 | |
| 25 | 0830-189 | SEAL,DRUM SHAFT | 1 | $10.97 | |
| 26 | 0827-011 | NUT,HF-CCW M18x1.5 | 1 | $4.54 | |
| 27 | 0823-018 | CLUTCH, ONE WAY ASM | 1 | $156.95 | |
| 28 | 0823-484 | CLUTCH CENTRIFICAL-6 PLATE-Z 2 | 1 | $243.95 | |
| 29 | 0828-076 | SHIM, 25 X 30 X .90 | 1 | $4.95 |
