AIR INTAKE ASSEMBLY
2008 THUNDERCAT AUTOMATIC TRANSMISSION 4X4
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0413-091 | DIVERTER,AIR-IN | 1 | $40.95 | |
| 2 | 0413-093 | DIVERTER,AIR INTAKE-BOTTOM | 1 | $42.95 | |
| 3 | 2406-509 | SHROUD,SPLASH | 1 | $37.95 | |
| 4 | 0623-362 | RIVET,PLASTIC-REINSTALLABLE | 1 | $0.68 | |
| 5 | 0423-551 | CLAMP,PLASTIC-SCREW-ROUND(63 DIAx13) | 1 | $2.33 | |
| 6 | 0423-342 | SCREW,SELF TAPPING-.1875 X .75 | 1 | $0.26 | |
| 7 | 0413-096 | CAP-AIR IN,BELT | 1 | $20.63 | |
| 8 | 0470-583 | BOOT,AIR IN-AIR BOX | 1 | $58.95 | |
| 9 | 0423-019 | CLAMP,HOSE-WORM (NORMA 50-70) | 1 | $2.47 | |
| 10 | 0423-716 | WINGNUT,NYLOC-M6X1.0 | 1 | $3.85 | |
| 11 | 0470-832 | LID,AIR BOX-FABRICATED | 1 | $42.95 | |
| 12 | 0470-828 | FILTER,AIR | 1 | $47.95 | |
| 13 | 0470-731 | CAGE,AIR FILTER | 1 | $49.95 | |
| 14 | 0570-221 | AIR BOX,BOTTOM & TOP-EMAWELD | 1 | $256.95 | |
| 15 | 0406-877 | BUMPER,SEAT | 1 | $3.57 | |
| 16 | 0470-442 | VALVE, AIR CLEANER | 1 | $13.73 | |
| 17 | 0470-638 | BOOT,THROTTLE BODY | 1 | $20.63 | |
| 18 | 0430-055 | SENSOR,AIR TEMP | 1 | $30.95 | |
| 19 | 5507-224 | O-RING,AIR TEMP SENSOR | 1 | $6.06 | |
| 20 | 1623-285 | CLAMP,HOSE-SPRING (12W X 22) | 1 | $2.88 | |
| 21 | 0410-152 | HOSE,OIL SEPERATOR | 1 | $35.95 | |
| 22 | 0470-718 | TANK,SEPARATOR | 1 | $64.95 | |
| 23 | 0410-150 | HOSE,CRANKCASE VENT #1 | 1 | $76.95 | |
| 24 | 0410-151 | HOSE,CRANKCASE VENT #2 | 1 | $106.95 |
