TRANSMISSION ASSEMBLY
2008 400 DVX
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3402-942 | SHAFT, COUNTER (NT:13) | 1 | $339.95 | |
| 2 | 3402-943 | GEAR, 2ND DRIVE (NT:18) | 1 | $169.95 | |
| 3 | 3446-362 | GEAR,3RD DRIVE | 1 | $196.95 | |
| 4 | 3446-363 | GEAR,4TH DRIVE | 1 | $148.95 | |
| 5 | 3446-364 | GEAR,5TH DRIVE | 1 | $169.95 | |
| 6 | 3423-689 | WASHER, 4TH | 1 | $2.95 | |
| 7 | 3423-702 | WASHER, 2ND (17X30X1.0) | 1 | $3.02 | |
| 8 | 3402-382 | SHIM,M25X32X1 | 1 | $6.34 | |
| 9 | 3402-975 | BEARING, COUNTERSHAFT LH | 1 | $64.95 | |
| 10 | 3423-066 | CIRCLIP,M25 | 1 | $6.47 | |
| 11 | 3402-976 | BEARING, COUNTERSHAFT RH | 1 | $76.95 | |
| 12 | 3435-099 | SHAFT,DRIVE | 1 | $268.95 | |
| 13 | 3446-365 | GEAR,1ST DRIVEN | 1 | $169.95 | |
| 14 | 3446-366 | GEAR,2ND DRIVEN | 1 | $164.95 | |
| 15 | 3402-944 | GEAR, 3RD DRIVEN (NT:26) | 1 | $180.95 | |
| 16 | 3402-945 | GEAR, 4TH DRIVEN (NT:23) | 1 | $181.95 | |
| 17 | 3402-946 | GEAR, 5TH DRIVEN (NT:22) | 1 | $181.95 | |
| 18 | 3402-950 | GEAR, REVERSE DRIVEN (NT:28) | 1 | $164.95 | |
| 19 | 3402-951 | DOG, REVERSE | 1 | $91.95 | |
| 20 | 3446-380 | BUSH,3RD DRIVEN GEAR | 1 | $45.95 | |
| 21 | 3423-036 | WASHER,25MM | 1 | $4.54 | |
| 22 | 3446-273 | BUSHING, DRIVEN, GEAR | 1 | $33.95 | |
| 23 | 3003-320 | BEARING,BALL,RIGHT,M17X40X12 | 1 | $34.95 | |
| 24 | 3402-195 | SHIM,20MM | 1 | $4.95 | |
| 25 | 3423-421 | WASHER, SHIFT SHAFT (M25X34X1.0) | 1 | $5.51 | |
| 26 | 3402-903 | BEARING, DRIVE SHAFT LH | 1 | $126.95 | |
| 27 | 3402-912 | SEAL, DRIVE SHAFT OIL | 1 | $79.95 | |
| 28 | 3402-915 | BUSH, 1ST DRIVEN | 1 | $32.95 | |
| 29 | 3402-230 | BUSHING,M25X29X8 | 1 | $30.95 | |
| 30 | 3446-377 | SPROCKET,ENGINE(14T) | 1 | $74.95 | |
| 31 | 3446-416 | CHAIN ASSY | 1 | $260.95 | |
| 32 | 3446-417 | JOINT SET | 1 | $37.95 | |
| 33 | 3446-367 | RETAINER,CNTR SHAFT BRG,R | 1 | $13.73 | |
| 34 | 3423-018 | SCREW, 6X12 | 1 | $2.61 | |
| 35 | 3446-368 | RETAINER,DRIVE SHAFT OIL SEAL | 1 | $17.87 | |
| 36 | 3423-659 | BOLT, RETAINER | 1 | $2.06 | |
| 37 | 3402-947 | SHAFT, REVERSE IDLE | 1 | $58.95 | |
| 38 | 3402-948 | GEAR, REVERSE IDLE (NT:24) | 1 | $163.95 | |
| 39 | 3402-949 | BUSH, REVERSE | 1 | $35.95 | |
| 40 | 3402-209 | WASHER,M17X28X1.0 | 1 | $3.71 | |
| 41 | 3423-701 | WASHER (17X36X1.0) | 1 | $2.95 | |
| 42 | 3423-686 | WAVE WASHER | 1 | $8.95 | |
| 43 | 3423-518 | CIRCLIP | 1 | $3.71 | |
| 44 | 3423-651 | BOLT | 1 | $10.97 | |
| 45 | 3402-961 | PLATE, SPROCKET | 1 | $10.95 |
