REAR SUSPENSION ASSEMBLY
2008 400 DVX
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3406-061 | LEVER SET,REAR CUSHION | 1 | $567.95 | |
| 2 | 3406-095 | BEARING, REAR (20X26X12) | 1 | $50.95 | |
| 3 | 3406-096 | BEARING, CENTER (20X27X15) | 1 | $30.95 | |
| 4 | 3423-626 | NIPPLE, GREASE | 1 | $9.59 | |
| 5 | 3406-060 | SPACER,RR CUSH LEVER,FR | 1 | $37.95 | |
| 6 | 3406-063 | SEAL,CUSHION LEVER DUST | 1 | $17.95 | |
| 7 | 3423-591 | BOLT,RR CUSHION LEVER FRONT | 1 | $17.87 | |
| 8 | 3423-670 | NUT | 1 | $9.59 | |
| 9 | 3406-065 | SPACER,REAR CUSHION | 1 | $37.95 | |
| 10 | 3406-066 | SPACER,RR CUSH ROD,SIDE | 1 | $30.95 | |
| 11 | 3423-590 | BOLT,REAR CUSHION | 1 | $17.87 | |
| 12 | 3406-100 | SEAL, REAR | 1 | $10.97 | |
| 13 | 3406-068 | SPACER,RR CUSHION LEVER ,REAR | 1 | $30.95 | |
| 14 | 3406-067 | GUARD,REAR CUSHION LEVER | 1 | $45.95 | |
| 15 | 3423-662 | SCREW | 1 | $3.02 | |
| 16 | 3406-163 | ROD SET,REAR CUSHION | 1 | $501.95 | |
| 17 | 3406-064 | SPACER,RR CUSHION ROD | 1 | $50.95 | |
| 18 | 3423-589 | BOLT,RR CUSHION ROD | 1 | $18.95 | |
| 19 | 3423-863 | NUT | 1 | $4.54 | |
| 20 | 3423-893 | BOLT,10X58 | 1 | $6.34 | |
| 21 | 3406-158 | ABSORBER ASSY, REAR SHOCK | 1 | $2,892.95 | |
| 22 | 3423-856 | BOLT,LOWER | 1 | $4.13 |
