2008 Arctic Cat 366 AUTOMATICTRANSMISSION 4X4 FIS — CAMSHAFT/VALVE ASSEMBLY
2008 366 AUTOMATICTRANSMISSION 4X4 FIS
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0809-251 | CAMSHAFT-ASSEMBLY | 1 | $393.95 | |
| 2 | 0809-166 | SPROCKET,CAM | 1 | $54.95 | |
| 3 | 0829-036 | DOWEL,ALIGNMENT,M5 X 8 | 1 | $2.95 | |
| 4 | 0828-086 | WASHER,FASTENER-LOCK | 1 | $2.06 | |
| 5 | 0826-117 | SCREW,M6X1 X 12 | 1 | $0.85 | |
| 6 | 0809-165 | C-RING,CAMSHAFT | 1 | $2.61 | |
| 7 | 0809-145 | ARM,VALVE ROCKER,INTAKE-MACHINING | 1 | $108.95 | |
| 8 | 3304-007 | SCREW TAPPET ADJUSTING | 1 | $3.57 | |
| 9 | 3304-026 | NUT TAPPET ADJUSTING | 1 | $1.23 | |
| 10 | 0809-149 | ARM,VALVE ROCKER,EXHAUST-MACHINING | 1 | $108.95 | |
| 11 | 0809-141 | SEAT,VALVE SPRING | 1 | $8.21 | |
| 12 | 0809-190 | SEAL,VALVE STEM | 1 | $12.35 | |
| 13 | 0809-151 | SHAFT,ROCKER ARM | 1 | $26.95 | |
| 14 | 0831-053 | PLUG,ROCKER ARM | 1 | $16.49 | |
| 15 | 0830-143 | WASHER,COMPRESSION 14 X 19 X 1.35 | 1 | $13.73 | |
| 16 | 0809-188 | VALVE,INTAKE | 1 | $58.95 | |
| 17 | 0809-189 | VALVE,EXHAUST | 1 | $102.95 | |
| 18 | 0809-140 | SPRING,VALVE | 1 | $10.97 | |
| 19 | 0809-142 | RETAINER, SPRING | 1 | $16.49 | |
| 20 | 3303-044 | COTTER VALVE | 1 | $10.97 |
