CRANKCASE COVER ASSEMBLY
2007 400 DVX
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3403-220 | COVER,CLUTCH | 1 | $299.95 | |
| 2 | 3446-357 | GASKET,CLUTCH COVER(NA) | 1 | $37.95 | |
| 3 | 3423-540 | PLUG, OIL GALLERY | 1 | $6.75 | |
| 4 | 3402-436 | WASHER | 1 | $1.92 | |
| 5 | 3423-610 | PIN | 1 | $3.44 | |
| 6 | 3007-504 | BOLT,OIL PAN | 1 | $2.75 | |
| 7 | 3003-290 | GASKET,CHECK VALVE,6MM | 1 | $3.85 | |
| 8 | 3007-496 | BOLT,CYL HEAD | 1 | $3.16 | |
| 9 | 3423-885 | BOLT,RECOIL STARTER-6X12 | 1 | $2.61 | |
| 10 | 3402-011 | GASKET,OIL DRAIN PLUG- M12.1X16.2X3.7 | 1 | $3.44 | |
| 11 | 3423-705 | PLUG, OIL GALLERY (12X10) | 1 | $5.78 | |
| 12 | 3007-457 | BOLT | 1 | $3.16 | |
| 13 | 3402-009 | WASHER, DRIVEN, M6.2X11X1.2 | 1 | $2.47 | |
| 14 | 3409-042 | COVER,MAGNETO | 1 | $346.95 | |
| 15 | 3409-023 | GASKET,MAGNETO COVER(NA) | 1 | $17.87 | |
| 16 | 3402-898 | PLUG, CRANK HOLE | 1 | $27.95 | |
| 17 | 3423-061 | O RING D:3.1 ID:32.7 | 1 | $4.26 | |
| 18 | 3402-012 | GASKET, OIL PLUG,M13.8X18.8X0.4 | 1 | $10.97 | |
| 19 | 3402-040 | PLUG,14MM | 1 | $6.20 | |
| 20 | 3409-022 | COVER,STARTER IDLE GEAR | 1 | $71.95 | |
| 21 | 3423-713 | O RING (D:2.6,ID:69.6) | 1 | $50.95 | |
| 22 | 3423-898 | BOLT,M6X16 | 1 | $3.02 | |
| 23 | 3435-098 | COVER COMP,ENG SPROCKET | 1 | $118.95 | |
| 24 | 3007-488 | BOLT | 1 | $3.85 | |
| 25 | 3423-672 | WASHER (6.5X14X2) | 1 | $2.61 | |
| 26 | 3402-962 | PLATE, CHAIN GUIDE | 1 | $37.95 |
