CAM CHAIN ASSEMBLY
2007 400 DVX LIMITED EDITION
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3502-027 | CHAIN COMP,CAMSHAFT DRIVE | 1 | $196.95 | |
| 2 | 3402-848 | GUIDE, CAM CHAIN NO.1 | 1 | $67.95 | |
| 3 | 3402-930 | GUIDE, CAM CHAIN NO.2 | 1 | $64.95 | |
| 4 | 3402-849 | TENSIONER,CAM CHAIN | 1 | $108.95 | |
| 5 | 3423-561 | BOLT,CAM CHAIN TENSIONER | 1 | $12.35 | |
| 6 | 3423-142 | WASHER, CAM STOPPER ARM SUPPORT-M6X18 | 1 | $2.06 | |
| 7 | 3502-019 | ADJUSTER ASSY,TENSIONER | 1 | $227.95 | |
| 8 | 3402-850 | GASKET | 1 | $13.73 | |
| 9 | 3402-933 | PLUG | 1 | $37.95 | |
| 10 | 3402-932 | SPRING | 1 | $13.73 | |
| 11 | 3402-137 | GASKET, TENSIONER ADJUSTER (NA) | 1 | $6.34 | |
| 12 | 3004-475 | BOLT,6X25 (R/B 3007-509) | 1 | $2.95 | |
| 13 | 3402-929 | RETAINER, CAM CHAIN GUIDE NO.1 | 1 | $8.95 | |
| 14 | 3423-018 | SCREW, 6X12 | 1 | $2.61 |
