2006 Arctic Cat PROWLER XT 650 H1 AUTOMATIC 4X4 — TAILGATE ASSEMBLY
2006 PROWLER XT 650 H1 AUTOMATIC 4X4
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 0 | 2506-205 | TAILGATE ASSEMBLY - BLACK | 1 | $357.95 | |
| 1 | 1506-704 | BRACE,TAILGATE-BLACK | 1 | $58.95 | |
| 2 | 2506-056 | LATCH,TAILGATE-BLACK | 1 | $112.95 | |
| 3 | 1406-706 | BEARING,HANDLE | 1 | $2.06 | |
| 4 | 2406-369 | PANEL,TAILGATE OUTER BLACK | 1 | $180.95 | |
| 5 | 2406-365 | PANEL,TAILGATE INNER | 1 | $140.95 | |
| 6 | 1406-927 | SHAFT,PIVOT-TAILGATE | 1 | $26.95 | |
| 7 | 0623-784 | R/B 2623-163 | 1 | $0.35 | |
| 8 | 0423-101 | SCREW,BODY-6MM | 1 | $2.06 |
