2006 Arctic Cat 650 V-TWIN AUTOAMTIC TRANSMISSION 4X4 FIS CA — MAGNETO
2006 650 V-TWIN AUTOAMTIC TRANSMISSION 4X4 FIS CA
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3201-183 | ROTOR | 1 | $793.95 | |
| 2 | 3201-240 | KEY-WOODRUFF | 1 | $4.95 | |
| 3 | 3201-095 | BOLT-SOCKET,6X28 | 1 | $10.95 | |
| 4 | 3201-182 | STATOR | 1 | $707.95 | |
| 5 | 3201-243 | COIL-PULSING | 1 | $135.95 | |
| 6 | 3201-138 | PLATE | 1 | $3.95 | |
| 7 | 3201-111 | BOLT-FLANGED | 1 | $1.95 | |
| 9 | 3201-382 | CLAMP | 1 | $3.57 | |
| 10 | 3201-033 | CLAMP | 1 | $6.95 |
