REAR AXLE ASSEMBLY
2006 50 DVX
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3303-152 | SPACER RR WHEEL R | 1 | $20.63 | |
| 2 | 3303-151 | SHAFT RR WHEEL | 1 | $190.95 | |
| 3 | 3303-153 | SPACER RR WHEEL L | 1 | $20.63 | |
| 4 | 3304-565 | BOLT FLANGE 8*20 | 1 | $1.50 | |
| 5 | 3303-607 | WASHER SPRING 8MM | 1 | $0.81 | |
| 6 | 3303-149 | HOLDER SPROCKET | 1 | $45.95 | |
| 7 | 3303-426 | SPRKT FINAL DRIVEN | 1 | $66.95 | |
| 8 | 3305-347 | HUB ASSY REAR | 1 | $169.95 | |
| 9 | 3303-427 | COLLAR RR HUB | 1 | $20.63 | |
| 10 | 3303-466 | BEARING BALL RADIAL 6006/30*55*13 | 1 | $42.95 | |
| 11 | 3303-461 | SEAL DUST | 1 | $9.59 | |
| 12 | 3303-281 | WASHER 12.2*28*4 | 1 | $1.50 | |
| 13 | 3303-379 | BOLT FLANGE 12*28MM | 1 | $3.57 |
