2004 Arctic Cat 90 Y-12 YOUTH 4-STROKE — CAM CHAIN AND TENSIONER ASSEMBLY
2004 90 Y-12 YOUTH 4-STROKE
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3301-662 | CAM CHAIN TENSIONER | 1 | $58.95 | |
| 2 | 3301-661 | CAM CHAIN | 1 | $118.95 | |
| 3 | 3301-663 | GUIDE COMP CAM CHAIN | 1 | $47.95 | |
| 4 | 3301-664 | PIVOT,CAM CHAIN TENSIONER | 1 | $10.97 | |
| 5 | 3301-665 | OIL-RING | 1 | $4.54 | |
| 6 | 3301-666 | TENSIONER LIFTER GASKET | 1 | $6.95 | |
| 7 | 3301-667 | TENSIONER LIFTER | 1 | $74.95 | |
| 8 | 3301-668 | ADJUSER PLUG | 1 | $5.92 | |
| 9 | 3301-669 | PLAIN WASHER | 1 | $12.35 | |
| 10 | 3301-670 | CAM CHAIN ADJUSTER SPRING | 1 | $2.95 | |
| 11 | 3301-389 | HEX WASHER FACE BOLT | 1 | $1.95 |
