2004 Arctic Cat 90 Y-12 YOUTH 4-STROKE — AIR CLEANER ASSEMBLY
2004 90 Y-12 YOUTH 4-STROKE
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3301-306 | HEX BOLT | 1 | $1.95 | |
| 2 | 3301-814 | AIR CLEANER CASE | 1 | $72.95 | |
| 3 | 3301-815 | AIR CLEANER ELEMENT | 1 | $64.95 | |
| 4 | 3301-816 | CLEANER FILTER NET | 1 | $22.95 | |
| 5 | 3301-817 | AIR CLEANER COVER | 1 | $22.95 | |
| 6 | 3301-818 | HOSE CLAMP | 1 | $20.95 |
