REAR BODY PANEL ASSEMBLY
2004 650 V-2 4X4 FIS CA
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0506-821 | RACK,REAR-W/FENCE-BLACK | 1 | $1,130.95 | |
| 1 | 1506-177 | RACK, REAR W/FENCE - PLATINUM | 1 | $199.95 | |
| 2 | 8409-020 | SCREW,CAP-HFH M10X1.25X20 CL10.9 Z&Y | 1 | $0.54 | |
| 3 | 0411-647 | DECAL,REFLECTOR-RED | 1 | $4.95 | |
| 4 | 0423-101 | SCREW,BODY-6MM | 1 | $2.06 | |
| 5 | 0423-046 | RIVET, PLASTIC - DH - .246X.157-.394 BLK | 1 | $1.09 | |
| 6 | 1506-260 | FENDER,REAR-ROUTED(MARSH GREEN) | 1 | $276.95 | |
| 6 | 1506-259 | FENDER,REAR-ROUTED(RED) | 1 | $276.95 | |
| 7 | 0506-552 | FLARE, REAR RH | 1 | $79.95 | |
| 7 | 0506-553 | FLARE, REAR LH | 1 | $79.95 | |
| 8 | 0423-342 | SCREW,SELF TAPPING-.1875 X .75 | 1 | $0.26 | |
| 9 | 0423-355 | SCREW, SHOULDER-M6-1.0 X 18-BLK | 1 | $0.95 | |
| 10 | 0423-438 | NUT,T W/TEETH - M6 | 1 | $12.35 | |
| 11 | 1506-350 | FENDER EXTENSION-RH-ROUTED | 1 | $163.95 | |
| 11 | 1506-372 | FENDER EXTENSION,LH-ROUTED | 1 | $66.95 | |
| 12 | 0412-140 | SHIELD,HEAT (PSA) | 1 | $26.95 | |
| 13 | 0623-309 | SCREW, SELF TAP-PHPNH 12-11X3/4 A Z&B | 1 | $0.40 | |
| 14 | 0423-060 | CLIP, TINERMAN -C07508-8A-4 | 1 | $1.95 | |
| 15 | 0423-068 | SCREW,MACH-#10-32X3/4(BLK) | 1 | $0.35 | |
| 16 | 0123-010 | NUT,EXPANSION 10-32 | 1 | $6.75 |
