STEERING POST ASSEMBLY
2004 400 DVX
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3405-010 | SHAFT,STEERING | 1 | $479.95 | |
| 2 | 3405-014 | SEAL,STEERING SHAFT HLDR DUST | 1 | $17.95 | |
| 3 | 3405-013 | HOLDER,STEERING SHAFT | 1 | $54.95 | |
| 4 | 3423-602 | BOLT | 1 | $3.57 | |
| 5 | 3423-055 | O RING D:3.1 ID:16.8 | 1 | $2.75 | |
| 6 | 3405-038 | BUSH, STEERING SHAFT LOWER | 1 | $58.95 | |
| 7 | 3405-056 | SEAL,STEERING SHAFT DUST | 1 | $20.63 | |
| 8 | 3405-057 | SEAL,STEERING LOWER DUST | 1 | $20.95 | |
| 9 | 3423-676 | WASHER (12.5X32X2.3) | 1 | $2.06 | |
| 10 | 3423-624 | NUT | 1 | $3.71 | |
| 11 | 3423-877 | COTTER PIN,ROD END | 1 | $1.95 | |
| 12 | 3405-027 | HOLDER,HANDLE LOWER(BLACK) | 1 | $54.95 | |
| 13 | 3405-028 | HOLDER,HANDLEBAR | 1 | $33.95 | |
| 14 | 3007-238 | BOLT,EGR VALVE | 1 | $4.95 | |
| 15 | 3423-682 | WASHER | 1 | $3.30 |
