GEAR SHIFTING ASSEMBLY
2003 400 4X4 MANUAL TRANSMISSION ()
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3446-306 | FORK, GEAR SHIFT REVERSE | 1 | $126.95 | |
| 2 | 3446-155 | FORK,GEAR SHIFT,NO.1 | 1 | $122.95 | |
| 3 | 3446-156 | FORK,GEAR SHIFT NO.2 | 1 | $126.95 | |
| 4 | 3402-643 | SHAFT, GEAR SHIFT FORK | 1 | $35.95 | |
| 5 | 3007-373 | NUT | 1 | $3.16 | |
| 6 | 3423-142 | WASHER, CAM STOPPER ARM SUPPORT-M6X18 | 1 | $2.06 | |
| 7 | 3446-282 | SPRING,GEAR SHIFT CAM STOPPER | 1 | $26.95 | |
| 8 | 3446-048 | SUPPORT, CAM STOPPER ARM | 1 | $32.95 | |
| 9 | 3402-746 | STOPPER, SHIFT CAM | 1 | $26.95 | |
| 10 | 3423-141 | WASHER, GEAR SHIFT CAM STOPPER-M6X14 | 1 | $3.95 | |
| 11 | 3423-884 | BOLT,CTUTCH RELEASE ARM-M6X20 | 1 | $2.61 | |
| 12 | 3446-309 | GUIDE, GEAR SHIFT | 1 | $20.63 | |
| 13 | 3446-049 | PLATE, GEAR SHIFT CAM | 1 | $67.95 | |
| 14 | 3423-045 | PIN ,M4X13.8 | 1 | $3.30 | |
| 15 | 3423-370 | SCREW,6MM | 1 | $2.61 | |
| 16 | 3423-135 | RETAINER, CNTR SHAFT BRG-M6X16 | 1 | $5.92 | |
| 17 | 3402-051 | BEARING,M25 | 1 | $62.95 | |
| 18 | 3446-308 | CAM, GEAR SHIFT | 1 | $255.95 | |
| 19 | 3423-114 | MM (DOWEL) | 1 | $2.06 | |
| 20 | 3402-087 | SPRING,COMPRESSION,M4 | 1 | $3.30 | |
| 21 | 3423-044 | PIN,CAM GEAR,5MM | 1 | $5.37 | |
| 22 | 3446-313 | BASE ASSY, NEUTRAL SWITCH | 1 | $196.95 | |
| 23 | 3423-418 | BOLT, BASE ASSY | 1 | $3.30 | |
| 24 | 3446-157 | FORK,GEAR SHIFT NO.3 | 1 | $122.95 | |
| 25 | 3446-307 | SHAFT, GEAR FORK NO.2 | 1 | $58.95 | |
| 26 | 3446-310 | SHAFT, GEAR SHIFT | 1 | $169.95 | |
| 27 | 3402-093 | SPRING,PULL,M6 | 1 | $12.35 | |
| 28 | 3446-056 | STOPPER, GEAR SHIFT ARM | 1 | $12.35 | |
| 29 | 3402-094 | SPRING,TORSION,M26 | 1 | $12.35 | |
| 30 | 3446-054 | SPACER, GEAR SHIFT SHAFT | 1 | $20.63 | |
| 31 | 3402-068 | OIL SEAL,M13X22X6 | 1 | $17.87 |
