1998 Arctic Cat 500 4X4 — CRANKSHAFT ASSEMBLY
1998 500 4X4
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3402-372 | CRANKSHAFT SET | 1 | $995.95 | |
| 2 | 3402-376 | CONNROD | 1 | $196.95 | |
| 3 | 3402-377 | PIN,CRANK | 1 | $94.95 | |
| 4 | 3402-717 | BEARING (37X47X24.8) | 1 | $144.95 | |
| 5 | 3423-351 | WASHER,M37X55X1 | 1 | $12.35 | |
| 7 | 3402-378 | CRANKSHAFT SET,RH | 1 | $559.95 | |
| 7 | 3402-705 | CRANKSHAFT,LEFT | 1 | $454.95 | |
| 10 | 3402-384 | BEARING,M17X40X9.5 | 1 | $50.95 | |
| 11 | 3402-058 | BEARING,BALL, M40X80X18 | 1 | $156.95 | |
| 12 | 3402-054 | BALL BEARING ,M35X80X21 | 1 | $156.95 | |
| 13 | 3402-120 | RETAINER, CRANKSHAFT BEARING, R | 1 | $17.87 | |
| 15 | 3402-188 | RETAINER, OIL SEAL | 1 | $17.87 | |
| 16 | 3423-018 | SCREW, 6X12 | 1 | $2.61 | |
| 17 | 3402-373 | PISTON | 1 | $169.95 | |
| 18 | 3402-374 | RING SET,PISTON | 1 | $94.95 | |
| 18 | 3436-009 | RING SET,+020 | 1 | $94.95 | |
| 18 | 3436-010 | RING SET,+040 | 1 | $94.95 | |
| 19 | 3402-375 | PIN, PISTON | 1 | $58.95 | |
| 20 | 3423-344 | CIRCLIP,M23 | 1 | $3.71 | |
| 22 | 3402-051 | BEARING,M25 | 1 | $62.95 | |
| 23 | 3402-070 | OIL SEAL,M25X36X6 | 1 | $45.95 | |
| 24 | 3423-542 | SPACER | 1 | $52.95 | |
| 25 | 3423-063 | O RING, ID:44, OD:2.4 | 1 | $20.63 | |
| 26 | 3423-053 | O RING | 1 | $6.47 | |
| 27 | 3402-348 | SPACER, CRANKSHAFT | 1 | $47.95 | |
| 28 | 3007-391 | NUT,INTER COOLER BRKT | 1 | $3.16 | |
| 29 | 3402-387 | SEAL,OIL,M17X36X6 | 1 | $33.95 | |
| 30 | 3423-355 | CIRCLIP,FASTENER | 1 | $5.92 |
