FRONT BEVEL GEAR ASSEMBLY
1998 454 4X4
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 0 | 3402-004 | GEAR CASE FR -ASSY | 1 | $2,873.95 | |
| 1 | 3435-089 | FLANGE,FR DRIVE BEVEL GR | 1 | $205.95 | |
| 2 | 3435-029 | COLLAR, OUTPUT OIL SEAL | 1 | $45.95 | |
| 3 | 3435-030 | PLATE, OUTPUT YOKE OIL SEAL | 1 | $20.63 | |
| 4 | 3423-034 | WASHER,30MM | 1 | $5.51 | |
| 5 | 3423-060 | O RING D:1 ID:28 | 1 | $4.40 | |
| 6 | 3435-014 | GEAR, FR DRIVE BEVEL | 1 | $390.95 | |
| 7 | 3435-021 | HOUSING, FR DRIVE BEVEL GR | 1 | $187.95 | |
| 8 | 3435-022 | SHIM SET FR DRIVE BEVEL HSG | 1 | $50.95 | |
| 9 | 3423-178 | NUT, FR DRIVE BVL GR,16MM | 1 | $3.30 | |
| 10 | 3423-028 | WASHER,16MM | 1 | $5.95 | |
| 11 | 3402-016 | SPACER,25MM | 1 | $56.95 | |
| 12 | 3402-066 | BEARING,TAPER ROLLER (M25X52X16.25) | 1 | $114.95 | |
| 13 | 3402-065 | BEARING TAPER ROLLER, M25X52X19.25 | 1 | $133.95 | |
| 14 | 3423-064 | O RING D:2.4 ID:62.6 | 1 | $10.97 | |
| 15 | 3402-072 | OIL SEAL ,M34X52X9 | 1 | $23.39 | |
| 16 | 3007-377 | BOLT | 1 | $3.49 | |
| 17 | 3435-018 | GEAR, FR DRIVEN BEVEL | 1 | $383.95 | |
| 18 | 3435-017 | SHIM SET, FR DRIVEN BVL GR | 1 | $56.95 | |
| 19 | 3435-020 | SHIM SET, DRIVEN GEAR BEARING | 1 | $62.95 | |
| 20 | 3402-059 | BEARING, BALL (M70X110X13) | 1 | $156.95 | |
| 22 | 3402-185 | BRG, FR DRIVEN OUTPUT(BALL)(6.34MM DIA) | 1 | $58.95 | |
| 23 | 3435-013 | DIFFERENTIAL ASSY, FRONT | 1 | $1,387.95 | |
| 24 | 3402-057 | BALL BEARING ,M40X62X12 | 1 | $126.95 | |
| 26 | 3435-024 | HOUSING, FR DIF GEAR | 1 | $945.95 | |
| 27 | 3402-084 | UNION,M8 | 1 | $4.95 | |
| 28 | 3435-025 | CASE, FR DRIVEN GR BRG | 1 | $360.95 | |
| 29 | 3423-010 | BOLT, 10X110 | 1 | $5.51 | |
| 30 | 3402-012 | GASKET, OIL PLUG,M13.8X18.8X0.4 | 1 | $10.97 | |
| 31 | 3402-013 | GASKET, M16X22X2 | 1 | $3.16 | |
| 32 | 3403-021 | PLUG,DRAIN | 1 | $13.73 | |
| 33 | 3403-236 | PLUG 16MM | 1 | $15.11 | |
| 34 | 3402-197 | PLUG, FR DRIVEN GR CASE,36MM | 1 | $33.95 | |
| 35 | 3423-050 | O RING D:2.4 ID:131.4 | 1 | $26.95 | |
| 36 | 3423-061 | O RING D:3.1 ID:32.7 | 1 | $4.26 | |
| 38 | 3423-070 | RING,M22 | 1 | $3.57 | |
| 39 | 3435-007 | COUPLING, PROP SHAFT | 1 | $350.95 | |
| 40 | 3423-903 | BOLT,PROP SHAFT 10X45 | 1 | $3.71 | |
| 41 | 3007-391 | NUT,INTER COOLER BRKT | 1 | $3.16 | |
| 42 | 1402-620 | BLADDER,CASE | 1 | $12.35 | |
| 43 | 0123-811 | TIE,CABLE-4 INCH PLT1M | 1 | $0.26 | |
| 44 | 8428-002 | NUT,HEX FLG- CLINCH LOCK- M10-1.25 Z&Y | 1 | $5.09 |
